Volume and Triggers
In the Select Mode screen, you can choose:
Trigger Parameter
Test Mode
Use the arrows to scroll through the selection options and click Save
to complete.
In the Select Trigger screens, you can choose:
Begin / End Trigger Values
Begin / End Trigger Slopes
Note trigger options for the volume begin and end triggers. These are
set as the default options and cannot be changed by the user.
Trigger
Flow
Absolute Pressure
Low Differential
Pressure
10
(continued)
Flow, Absolute Pressure, or Low Pressure
Single or Continuous
Select from available values
Positive or Negative
Units Trigger Values
Std L/min 0.1, 0.5, 1, 2, 3, 5, 7.5, 10, 20
+/–
kPa 90, 95, 98, 100, 102, 104, 107, 110
cmH O 0.5, 1, 2, 3, 4, 5, 10
+/–
2
Gas Flow Multi-Meter 5200 Series
