Intergrated Circuits
Component
AD7715
AD780
74HC4050
74LS08
74LS244
HP 5082-2810
Capacitors
Component
10µF ± 20% Tantalum (16 V)
0.1µF Ceramic(X7R ± 20%)
33pF ± 2% Ceramic
Open Circuit
Resistors
Component
10kΩ ± 5% 0.25W
Carbon Film Resistor
3.3kΩ ± 5% 0.25W
Carbon Film Resistor
1MΩ±5% 0.25W
Carbon Film Resistor
Short Circuits
Link Options
Component
Pin Headers
Shorting Plugs
REV. A
COMPONENT LISTING AND MANUFACTURERS
Location
IC1
IC2
IC3
IC4
IC5
D1 & D2
Location
C1, C3, C5
C2, C4, C6, C9,
C10, C11
C13, C14
C7, C8,
Location
R5, R6
R4
R3
R1, R2
Location
Lk1 (4x2 way)
Lk2, Lk3
( 2x2 way)
Lk4
(3x2 way)
Lk5, Lk16
(1x2 way)
Pin Headers
(7 required)
Vendor
Analog Devices
Analog Devices
Philips
Texas Instruments
Texas Instruments
Hewlett Packard
Vendor
AVX- Kyocera
Mftrs No TAG106MO16
Philips
Mftrs No. CW20C 104M
Philips
Mftrs No. 683 34339
Vendor
Bourns
Bourns
Bourns
Vendor
Harwin
Mftrs No. M20-9993606
Harwin
Mftrs No. M7571-05
