CODEGRIP
programmer /
debugger module
Envisioned as the unified development platform, EasyAVR PRO v8
development board is equipped with the onboard CODEGRIP programming/
debugging module, which supports various high pin count 8/16 bit AVR®
MCUs, produced by Microchip. The CODEGRIP module can be interfaced with
the host computer over the USB-C connector.
Besides the USB cable, the CODEGRIP module
the WiFi network. This is a revolutionary new feature, which allows some
unique usage scenarios, currently not available on any other programming/
debugging solution in the world. The WiFi connectivity option of the
CODEGRIP module offers a complete autonomy of the development board.
Running in hazardous environment while debugging the software in real
time, programming the MCU with a new software during exposure, having the
sensor responses collected and logged remotely from several different base
points, debugging a drone firmware while it is in mid-air... These are just a
simple examples of what EasyAVR PRO v8 development board can offer.
CODEGRIP module is equipped with LED indicators that provide visual
feedback about its status:
POWER (GREEN) indicates that the development board is powered on
USB-LINK (YELLOW) After the host OS completes the USB enumeration of the
CODEGRIP module, this LED will indicate that the connection has been established
NET-LINK (AMBER)
network, this LED will indicate that the connection has been established
ACTIVE (RED)
CODEGRIP module is in the bootloader mode, this indicator will blink. Normal
operation of the CODEGRIP module is indicated by the ACTIVE LED being
(1) can be accessed over constantly turned ON
DATA (BLUE)
and the CODEGRIP module
The onboard CODEGRIP module
utilizes a HID driver model, which is natively supported by the computer OS.
This makes its installation very easy and straightforward in the case when
the USB cable is used. As soon as the USB cable is connected to the host PC,
the CODEGRIP module is enumerated and the development board is ready to
be used.
CODEGRIP module is supported by CODEGRIP Suite. Detailed explanation
on how to configure and use the CODEGRIP module on the EasyAVR PRO
v8 development board, can be found in the CODEGRIP manual, and can be
downloaded on the following link:
When the CODEGRIP module is connected to the WiFi
Indicates the operational state of the CODEGRIP module: when
Indicates that there is a data transfer ongoing between the MCU
(1) requires no additional drivers, as it
www.mikroe.com/manual/codegrip
