Fimco ATVBK-700-QR Owner's Manual

General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
boom kit assembly.
Retain a copy of your receipt for your unit,
as it will be required to validate any warranty service
Products are warranted against manufacturer or workmanship
defects for one year from date of purchase for home owner
usage and 90 days for commercial usage.
For technical assistance, call: TOLL FREE @ 1-800-831-0027
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...

Correct Part Description and/or part number

Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
Model: ATVBK-700-QR (5302337)
(7-Nozzle Boom Assembly w/Connecting Fittings)
(Tank NOT Included with Boom Kit)
Technical Specifications

7-Nozzle Boom Assembly

140" Spray Coverage

Break-Away Outer Booms

AIXR11002VP, #2 (Yellow) 110° tips (**)

Check Valve Strainers, 50 Mesh, 5 PSI
(**) These tips provide excellent chemical and acid resistance
with an exceptionally long wear life.
110° wide tapered, flat spray angle with air induction technol-
ogy for better drift management.
Compact size prevents tip damage.
Assembly Instructions
Remove the parts to the boom assembly from the carton.
Refer to the parts list/exploded view drawing to help identify
all the components.

Make sure the contents of the sprayer's carton match the
items shown on page 2 of the manual.

Follow the steps on pages 3, 4 & 5 to properly assemble
the boom kit to your sprayer.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5008422 (11/18)]
Page 1
