U-Line H-10801 Instructions Manual

H-8945, H-8946, H-8947
π
H-10801, H-10802
TOOL CABINETS
TOOLS NEEDED
12 mm Combination Wrench
13 mm Combination Wrench
Tool Cabinet x 1
(for H-8945 & H-8946 only)
CAUTION! Do not open more than one loaded
drawer at a time.
• Lock drawers before moving.
• Do not stand on the product. You may fall, which
may cause personal injury.
• Do not mount the product on truck bed or any other
moving object.
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Phillips Screwdriver
Swivel Caster x 2 Rigid Caster x 2
5/16 x 5/8"
Hex Head Bolt x 16 Hex Head Bolt x 16
(for H-8947 only)
M16 x 15
Screws
PARTS
Handle x 1
M8 x 25 M16 x 15 Screw x 4
SAFETY
• Apply brakes on swivel casters when not moving unit.
• Do not pull. Push to move.
• Do not step in the drawers. You may fall, which may
cause personal injury.
• Lubricate the top and bottom channels of the
drawer slides at least twice a year.
ASSEMBLY
ATTACH HANDLE
1. Insert handle into slots on side of tool cabinet.
(See Figure 1)
2. Insert four screws with washers through the holes in
the handle. Secure using Phillips screwdriver, but do
not tighten.
3. Once all screws are installed, tighten screws
completely.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Drawer Liner x 4
Cabinet Key x 2
(6 for H-8946)
(11 for H-8947)
Lock Washer x 16 Washer x 4
(for H-8945 & (H-8947 x 20)
H-8946 only)
0323 IH-8945
