HDMI EXTENDER 4K@60HZ

TECHNICAL PARAMETERS

ITEMS
VIDEO
Input Interface
Output Interface
HDMI Length
Maximum transfer rate
Maximum transmission
bandwidth
EDID passthrough
Compatibility
Resolutions
Transmission distance
AUDIO
Input interface
Output interface
Audio formats
COMMAND SIGNAL
IR Interface
Receiving range
Infrared frequency
POWER
Power Supply
Power Consumption
OPERATING ENVIRONMENT
Working temperature
Storage temperature
Humidity
PHYSICAL PROPERTIES
Housing
Weight
Color
Dimensions
Protection
TRANSMITTER
1x HDMI Type A Female
1x HDMI Type A Female; 1x RJ45 Female 1x HDMI Type A Female
≤ 5m
18Gbps
600MHz
Yes
HDMI 2.0 (Deep color, 4K, HDR, YUV4:4:4)
HDCP 2.2, HDCP1.4
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz,1080p@50/60Hz, 3840x2160@24/25/30/50/60Hz,
3440x1440, 2560x1440, 2560x1080, 2048x1080, 1920x1440, 1920x1080,
1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768,
1600x900,1024x768, 800x600
4K transmission distance 50m; 1080p transmission distance 70m
1x HDMI Type A Female
1x HDMI Type A Female
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
1x 3.5mm IR OUT Female
≤5m
20KHz~60KHz
DC5V/2A
TX+RX<5.5W
-20°~60°C
-30°~70°C
0~90% RH (No condensation)
Metal
TX: 130g
Black
75.0(L)*60.0(W)*21.0(H)mm
ESD protection; 1a Contact discharge level 2 (±4KV); 1b Air discharge level 3
(±8KV); Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
RECEIVER
1x RJ45 Female
≤ 5m
N/A
1x HDMI Type A Female
1x 3.5mm IR IN Female
PoC (Powered by TX)
RX: 130g
