PFEIFFER UPHOLSTERED BED FULL & QUEEN - ASSEMBLY INSTRUCTIONS

PARTS INCLUDED

A. HEADBOARD (1)
B. SIDE RAILS (2)
C. FOOTBOARD (1)
D. SLAT ROLL (1)
E. CENTER SUPPORT SLAT (1)
F. CENTER SUPPORT SLAT FOOT (WITH ADJUSTABLE GLIDE) (1)

TOOLS NEEDED

Phillips- - head Screwdriver (not included)
-
ASSEMBLY INSTRUCTIONS
Bed must be assembled by at least two people.
Please read instructions carefully before assembling bed.
Use the above parts and hardware list to identify each component.
Keep all packing materials until assembly is complete to avoid loss of smaller parts.
1. Stand the Headboard (A) upright and attach Side Rails (B).
attach the Footboard (C), then tighten with Allen Head Bolt (2) and Allen Key (1), as shown in Diagram I.
2. Lock the Headboard (A) and Footboard (C) with Curved
then tighten with Spanner
Attach the Center Support Slat Foot (F) to the Center Support Slat (E), as shown in Diagram III.
3.
Attach the L-Shaped Brackets (4) to the ends of Center Support Slat (E), and tighten with Allen Head
4.
Bolt (2) and Allen Key (1). Attach the L-Shaped Brackets (4) to the Headboard (A) and Footboard (C), and
tighten with Allen Head Bolt (2) and Allen Key (1), as shown in Diagram IV.
Place the Slat Roll (D) into the cleats on the inside of the Side Rails (B).
5.
Screw the ends of the slats to the cleats using Screws (3), as shown in Diagram V.
NO.
1
2
3
4
5
6
7
8
9
rench ( ), as shown in Diagram II.
W
9
Page 1 of 2
DESCRIPTION
Allen Key
Allen Head Bolt (0.6cm Diam)
Screw (3cm)
L-Shaped Bracket
Lock Washer
Repeat the same proceduce to
ashers ( ), Lock W ashers ( ) and Nuts ( ),
W 6
Qty
1 Piece
12 Pieces
30 Pieces
2 Pieces
4 Pieces
4 Pieces
4 Pieces
4 Pieces
1 Piece
8
