Chesterfield Bunk Bed – Assembly Instruction
Made In China
!
WARNING: Read all instructions before assembling
this product. KEEP INSTRUCTIONS FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You
can also order parts writing to the address above. Include the product model number,
color, and a brief description of the part. Call 1-800-762-1751
CARE AND CLEA
NINGCAGCARE AND CLEANING
DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft dry cloth add
period & Dab spills quickly with a soft cloth. Vacuum to remove dust.
If the Bunk Bed is to be stored, store in a cool dry place andcarefully package all original
hardware to protect from loss.
Page 1 of 11
Advertisement
Related Manuals for RH Baby&child Chesterfield Bunk Bed
Summary of Contents for RH Baby&child Chesterfield Bunk Bed
- Page 1 Chesterfield Bunk Bed – Assembly Instruction Made In China WARNING: Read all instructions before assembling this product. KEEP INSTRUCTIONS FOR FUTURE USE. CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact us first. You can also order parts writing to the address above.
- Page 2 Chesterfield Bunk Bed – Assembly Instruction IMPORTANT SAFETY INFORMATION FOR BUNK BED Follow the information on the WARNINGS appearing on the upper bunk end structure and on the carton. Do not remove warning label from bed Always use the specified size mattress, to help prevent the likelihood of entrapment or falls Surface of mattress must be at least 5 inches below the upper edge of guardrails on top bunk Do not allow children under 6 years of age to use upper bunk.
- Page 3 Chesterfield Bunk Bed – Assembly Instruction PARTS INCLUDE (1) Left Bunk End - 1 pc (2) Right Bunk End - 1 pc (3) Back Side Rail - 2 pc (4) Front Side Rail - 2 pcs (5) Back Guard Rail - 1 pc...
-
Page 4: Hardware List
Chesterfield Bunk Bed – Assembly Instruction HARDWARE LIST HARDWARE & PARTS ENCLOSED Threaded Rod 17 pcs Curved Washer 17 pcs Spring Washer 17 pcs 17 pcs Spanner Wrench 1 pcs Big Screw (4cm) 17 pcs Medium Screw (2.5cm) 65 pcs... - Page 5 Chesterfield Bunk Bed – Assembly Instruction Process: Step 1: Attach Bed Feet (7) to left Bunk End (1) and Repeat the procedure with Right Bunk End (2). Page 5 of 11...
- Page 6 Chesterfield Bunk Bed – Assembly Instruction Step 2: Attach Front Side Rail (4) to Left Bunk End (1) and Right Bunk End (2). Insert the Threaded Rods (A) into the holes on the end of Front Side Rail (4), and insert Curved Washers (B), Spring Washers (C), and Nuts (D) onto the Threaded Rods (A) to attach theLeft Bunk end (1) and Right Bunk End (2).
- Page 7 Chesterfield Bunk Bed – Assembly Instruction Step 3: Attach Back Guard Rail (5) to Left Bunk End (1) and Right Bunk End (2), by using the Allen Key (I) to tighten Allen Head Bolts (J) and Big Flat Washers (K);...
- Page 8 Chesterfield Bunk Bed – Assembly Instruction Step 6: Lay the Twin Slat Roll (10) in between the Front Side Rail (4) and Back Side Rail (3), then tighten with Big Screws (F). -The webbing on the slats should be on the bottom side.
- Page 9 Chesterfield Bunk Bed – Assembly Instruction Step 7: Lay the Twin Panels (9) on top of the Slat Roll (10), and tighten with Medium Screws (G). - Numbers on the panel show the locations to tighten the Medium Screws. Page 9 of 11...
- Page 10 Chesterfield Bunk Bed – Assembly Instruction Step 8:Attach Ladder (8) to Front Side Rail (4). Page 10 of 11...
- Page 11 Chesterfield Bunk Bed – Assembly Instruction Step 9:Install Bedding: BEDDING SPECIFICATION: The following size mattress and Foundation are specified for use with this Bunk bed; 38”W× 75”L ×7”H on upper bunk, MATTRESS: × 75”L ×10”H on lower bunk (twin size) 38”W...
