Made in Vietnam
Distributed in the U.S.A. by:
Restoration Hardware Baby & Child
2900 North Macarthur Dr. Tracy,
CA95376, USA
www.rhbabyandchild.com
Distributed in Canada by:
Restoration Hardware Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia V6E4N7
WARNING: Read all
instructions before assembling this
product. KEEP INSTRUCTIONS
FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to the address above. Include
the product model number, color, and a brief description of the part. Call 1-800-762-1751.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft, dry cloth.
Blot spills immediately and wipe with a clean damp cloth. If the crib is to be stored, store in a cool dry place and carefully package all original
hardware to protect from loss.
TOOLS AND INSTALLATION
Tools Necessary: Allen Key (included)
NOTE: It may be easier to assemble product with two people.
NOTE: When inserting bolts, turn clockwise until tight. Then loosen
tighten. Use wax or soap on all bolts to facilitate assembly
All Restoration Hardware cribs are designed to meet the highest safety
standards and comply with all U.S. and Canadian cribs and cradles regulations.
1
3
-
of a turn. After crib is completely assembled, return to each bolt and
2
4
Page 1 of 10
Advertisement
Related Manuals for RH Baby&child WILKES CONVERSION CRIB
Summary of Contents for RH Baby&child WILKES CONVERSION CRIB
- Page 1 All Restoration Hardware cribs are designed to meet the highest safety standards and comply with all U.S. and Canadian cribs and cradles regulations. Made in Vietnam Distributed in the U.S.A. by: Restoration Hardware Baby & Child 2900 North Macarthur Dr. Tracy, CA95376, USA www.rhbabyandchild.com Distributed in Canada by:...
- Page 2 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING: Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death. ·...
- Page 3 IMPORTANT SAFETY INFORMATION FOR CRIBS CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES. WARNING Do not use this crib if you cannot exactly follow the instructions that come with it.
- Page 4 IMPORTANT SAFETY INFORMATION FOR TODDLER & DAY BEDS WARNING: ENTRAPMENT / STRANGULATION HAZARD Infants have died in toddler beds from entrapment and strangulation. Failure to follow these warnings and the assembly instructions could result in serious injury or death. NEVER use bed with children under 15 months. NEVER place bed near windows where cords from blinds or drapes may strangle a child.
-
Page 5: Item Identification
ITEM IDENTIFICATION For ease of identification, all parts are labeled to correspond to the step number in which the part is used. Step #1 Side frame and headboard assembly (Page 6 of 10). Step #2 Mattress support and stabilizer rail assembly. Mattress height adjustment (Page 7 of 10). - Page 6 STEP #1 HEAD BOARD & SIDE RAIL PANEL ASSEMBLY STEP# 1.1 Bring the headboard and the side panel in upright position. NOTE: On both side ends of the headboard are holes for the bolt to pass through that correspond to the holes located on both side ends of the side rail panel with pre-installed nuts.
- Page 7 STEP #2 DETAIL B MATTRESS SUPPORT ARM ASSEMBLY STABILIZER RAIL ASSEMBLY LOCK MATTRESS HEIGHT ADJUSTMENT HEX NUT WASHER STEP #2.1 Lay mattress support flat with stabilizer rail on each side. ALLEN BOLT (BB) NOTE: On each end of the arm of the mattress support, there is a hole for the bolt to pass through that corresponds to the holes located in the frame of PLAIN ALLEN...
- Page 8 STEP #3 SUPPORT SLAT INTO SIDE RAIL PANEL ASSEMBLY DETAIL D STEP #3.1 On inside face of both side panels are pre-installed metal brackets, designed to hold the stabilizer rails. Set both ends of the stabilizer rails into brackets, as illustrated in DETAIL D. STEP #3.2 Once the stabilizer rails are set, gently tilt the crib as illustrated in DETAIL E, then fasten the stabilizer rails with...
- Page 9 STEP #4 FRONT RAIL ASSEMBLY STEP #4.1: On both ends of the front rail are holes for the bolt to pass through and pre-installed wooden dowels that correspond to the holes on the posts for both side rail panels with pre-installed nuts and pre-bored holes for the wooden dowels. Align and insert the wooden dowel on the lower front rail into the lower holes of both side rail panels, then engage the top bolt in each hole and tighten with Allen wrench provided, as in DETAIL G &...
- Page 10 STEP #5 DETAIL I TODDLER RAIL ASSEMBLY (DD) STEP #5.1: Remove the front rail panel of the crib by loosening all the bolts installed. STEP #5.2: Gently tilt the crib and release the bolts underneath the metal brackets holding the stabilizer rails. STEP #5.3 Gently remove the mattress support and slightly loosen the bolt METAL...
