CAL LU M T W I N / FU LL P L AT FO RM CA N OP Y B ED WI TH HEA DBOA RD
PARTS I N CLU DE D:
[1]
HEADBOARD PANEL
A
[2]
HEADBOARD POST
B
[2]
FOOTBOARD POST
C
[2]
LONG SIDE RAIL
D
[2]
SHORT SIDE RAIL
E
[1]
SLAT ROLL
F
[2]
LONG CANOPY RAILS
G
[2]
SHORT CANOPY RAILS
H
TOO L S N E E D E D :
Phillips-Head Screwdrive ( not included)
ASS E M BLY I N ST R UCT I O N S :
Note:
Two adults are recommended to assemble this bed.
STEP 1:
Attach the Long Side Rails (D) to the
Short Side Rails (E).
E
D
E
NO.
ITEM
1
2
3
4
5
6
7
8
9
10
D
Page 1 of 6
DESCRIPTION
Long Bolt 5/16" x 2-1/4"
Flat Washer 5/16"
Spring Washer 5/16"
Long Screw 8 x 30mm
Short Screws 8 x 15mm
Allen Key 4mm
Connecting Bolt 6mm
Assembling Insert
Camlock Wheel
Allen Key 5mm
QTY.
20 pcs.
20 pcs.
20 pcs.
4 pcs.
20 pcs.
1 pc.
4 pcs.
4 pcs.
4 pcs.
1 pc.
