Diesse VES MATIC Original Quick Start Manual

– Quick Start Guide –
ALWAYS REFER TO THE USER MANUAL FOR ALL THE DETAILS ON THE

ANALYSIS CYCLE EXECUTION

Turn on the instrument
-
Press the START button
-
Open the top lid
-
Insert the test tubes until they are fully flush, orienting them
-
with the label facing the mark on the plate
Close the top lid
-
Press the button corresponding
-
mode you want to start
Automatic reading of the barcodes and indication on the display of
-
the number of samples present
Automatic mixing of the samples
-
Blood level reading at time 0'
-
Sedimentation
-
Blood level reading after 30 minutes (1H) or after 60 minutes (2H), with any
-
intermediate readings for sedimentation kinetics (1H KYN or 2H KYN)
ANALYSIS CYCLE EXECUTION – RANDOM ACCESS
During a cycle it will be possible at any time (excluding the cycle modes in kinetics
-
and the mixing phase) to insert a new sample
Mix the sample thoroughly before inserting it into the instrument (at least 8 times per
-
complete inversion)
Press the ADD button
-
Wait for the indication authorizing the opening of the top lid
-
Open the top lid and insert the test tube (as described above) in the position
-
indicated in the warning window that appears on the screen
Close the top lid
-
Automatic reading of the barcode of the added sample
-
Blood level reading at time 0'
-
Sedimentation
-
Blood level reading after 30 minutes (1H) or after 60 minutes (2H)
-

RESULTS

At the end of the analysis, the instrument displays the result for each sample in mm/h:
It will be green for ESR within the normal range
-
It will be red for ESR outside the normal range (which can be defined in the settings
-
menu under "THRESHOLD VALUE")
At the end of the analysis, the results are printed automatically (default ON)

ARCHIVE

Press the ARCHIVE button
-
Select the samples for consultation/printing of the results and of the
-
sedimentation graphs
Rev. 0 – 30/09/2022
Displayed on the instrument by pressing the key
OPERATION OF THE INSTRUMENT.
to the cycle
1/3
