CrystalLink USB3.1
Features and Benefits
Extends USB 1.1, USB2.0 and USB3.1 devices
■
beyond the standard 3m cable limit, point-to-
point connection, up to 330ft (100m) using
CAT6 cable or 660ft (200m) using multimode
fiber.
Supports all USB1.1, USB2.0 and USB3.1 Gen 1
■
devices simultaneously at full 5Gbps
bandwidth.
Four available USB-A Gen 1 ports on the
■
receiver unit, each with 1.5A power.
Expandable to 30 ports with the use of USB
hubs
One 100/1000 Ethernet channel for LAN pass-
■
through.
Optimum performance with CAT6a and CAT7
■
(solid core) UTP/STP cabling.
Plug-and-Play installation, no configuration,
■
driver installation or set-up required.
Supports all major operating systems:
■
Windows®, Mac OS X® and Linux®.
Transmitter and Receiver units require a
■
+24VDC power adapter (included).
USB3.1 5Gbps CATx/FIBER EXTENDER
USB3.1 Gen 1 data rate up to 5Gbps
►
Supports all USB 3.1, 2.0, 1.1 devices
►
simultaneously at full bandwidth
Single CAT6a/ CAT7 cable, up to 330ft (100m) and
►
multimode fiber up to 660ft (200m)
100/1000 Ethernet channel, LAN pass-through
►
Point-to-point connection
►
Product Overview
The CrystalLink USB 3.1 extender is a professional and
industrial grade extender, ideally suited for remote
and secure operation at USB3.1 data rates while
simultaneously supporting backward compatibility
with USB1.1 and USB2.0 devices at their respective
data rates. This extender can support a combination
of USB peripherals such as USB3.1 cameras, USB2.0
hard drives and USB1.1 keyboard and mouse over a
single CAT6 cable at distances up to 330ft (100
meters) or 660ft (200m) using multimode fiber.
This high-performance USB 3-2-1 extender is ideal for
locating various USB workstation devices in safe and
secure operating environments, conveniently away
from any hazardous host device location.
Data transmission is point-to-point, using a single
CAT6a/7 UTP/STP solid core cable or multimode fiber
cable with duplex LC type connectors. The connection
of network enabled host devices is another feature of
this high-performance extender that also supports
transparent USB extension, plug-and-play with no
software drivers required and compatibility with all
major operating systems.
