panda futura 5
English Manual
EN 12182
EN 12183
© 2008 R82 A/S. All rights reserved.
The R82 logo and the Panda Futura chairs are registered trademarks of R82 A/S.
2023-04 - rev. 14.0
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R82 Panda Futura 5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Etac R82 Panda Futura 5

  • Page 1 panda futura 5 English Manual EN 12182 EN 12183 © 2008 R82 A/S. All rights reserved. The R82 logo and the Panda Futura chairs are registered trademarks of R82 A/S. 2023-04 - rev. 14.0...
  • Page 2: Table Of Contents

    CONTENTS Intended purpose............... 3 Declaration of Conformity ..........3 R82 Warranty ..............3 Safety ................3 Disposal ................3 Service information ............4 Washing ................4 Warewashing machine ............4 Disinfection ................ 4 Accessories and spare parts ..........4 Service interval ..............4 Service Check List .............
  • Page 3: Intended Purpose

    There are no known contra indications Presales information and instructions are available at www. Precautions etac.com, under your product, in the documents section. Special attention should be given to the considerations about the configuration of the product and the use of accessories for users with limitation in their: •...
  • Page 4: Technical Data

    • Information regarding frame and seat combinations including max. load in combination can be found at: etac. com. • Information about transportation can be found in the document “M1460 Transportation in Motor Vehicles”...
  • Page 5 Service & maintenance information Service and maintenance of a medical device is wholly the responsibility of the owner of that device. Failure to service and maintain a device in accordance with the instructions may invalidate the device’s warranty. Furthermore, failure to service and maintain a device may compromise the clinical condition or safety of users and/or their caregivers. Do not perform service and maintenance while the user is in the product.
  • Page 6 See page 7 89811-5xx 89930-5 See page 9 89130-20 See page 9 89642-xxx See page 10 89658-xxxx 8910301-4 See page 11 8910301-5 See page 12 89619-x See page 12 8910725-5...
  • Page 7: Measurements

    MEASUREMENTS Panda Futura 5 Active Panda Futura 5 Standard mm (inch) mm (inch) Effective seat width (A) 350 (13¾") 350 (13¾") Effective seat depth (B) 430 (17") 430 (17") Backrest height (C) 590 (23¼") 590 (23¼") Back width, top of backrest (F2) 350 (13¾") 380 (15") Back width, bottom of backrest (F1)
  • Page 8: Product Identification

    PRODUCT IDENTIFICATION (XX)XXXXXXXXXXXXXX(XX)XXXXXX(XX)XXXXXX Panda Futura 5 seat A) Manufacturer The label is placed on the seat under the cushion. In the top left-hand corner. B) Serial number The label is placed on the seat under the cushion. In the top right-hand corner.
  • Page 9: Symbols

    Symbols For indoor and outdoor use Consult instructions The latest version of the instructions is always available on the Etac website and can be printed in larger sizes Warning This symbol appears in the User Guide along with a number referring to the instructions below.
  • Page 10 READY FOR USE The Panda Futura 5 seat is available as (A) STANDARD and as (B) ACTIVE. The main difference between the two models is the shaping of the seats. The ACTIVE seat is shaped to allow greater upper extremity move- ment and is ideal for more active children.
  • Page 11 BACK RECLINE Push the handle (A) up to recline the back. To prevent sudden recline, firmly grab the back of the chair before pushing the handle. LUMBAR SUPPORT The Panda Futura 5 is delivered including adju- stable lumbar support in the back cushion. Move the lumbar support up or down (A) according to the need for support.
  • Page 12 POMMEL The Panda Futura 5 is prepared for mounting of pommel. * Fasten the mounting bracket by using the enclosed 4 mm Allen key (A). * The pommel is fitted into the bracket and is adjusted in depth by using the handle (B). SEAT EXTENSION The Panda Futura 5 is prepared for mounting of seat extension.
  • Page 13 BACK EXTENSION The Panda Futura 5 is prepared for mounting of back extension. * Mount the bar from the back extension into the fitting on the back and fasten with the thumbscrew (A). * Loosen the thumbscrew (A) or (B) to adjust the height.
  • Page 14 SIDE SUPPORTS The Panda Futura 5 is prepared for mounting of side supports. * Place the side supports in the slots. * Place the nuts, one by one, through the hole (A) in the back and into the slots in the side support.
  • Page 15 ARMREST Height adjustment: Open the handle (A) to move the armrest into po- sition. Place the small screw (B) in desired height position. Close the handle after adjustment. Tilting the armrest cushion: Loosen the handle (C). Adjust and angle of the armrest cushion sidewise: Loosen the screws (D) beneath the cushion.
  • Page 16 CROSS VEST The vest and cross vest can be opened and closed by using the buckles and the zip. * Mount the shoulder straps through the hole in the back cushion and into the fixlock fittings on the upper back (A). * Mount the upper straps in the sides in the fixlock fittings on the back (B).
  • Page 17 PANDA FUTURA 5 ON HIGH-LOW:X FRAME SIZE 2 This combination must not be used for severely spastic children with vigorous movements. To mount the seat: Place the seat in the adapter and push it all the way back, until it „clicks” into place. Lock the red handle (A) to secure the stability of the seat.
  • Page 18 PUSH BRACE FOR HIGH-LOW:X INDOOR FRAME Depth adjustment: Loosen the screws (A) on both sides of the frame and adjust the depth of the push brace. The push brace adjusts in two positions and clicks into place with the security nut. Fasten in the required position.
