Wall Mounting

DANGER! Danger to life! When drilling, keep a sufficient distance from power lines
that are close to the holes to be drilled.
There is a high risk of fire or life-threatening electric shock.
ATTENTION! Damage to property! When drilling, keep a sufficient distance from
water pipes that are close to the holes to be drilled. There is a risk of water damage.
1. Choose the right part of the wall.
2. Before installing the warmer, mark the places where you want to attach the wall
brackets to the wall and drill the holes in the wall with a suitable drill. (Fig-2, p1-p2)
3. Insert the wall plugs (9) in the holes made and screw the plastic fastener (8) to the
wall with the washer (7) and 4.8 x 60 mm screw (6). (Fig-2, p3)
4. Screw the bracket (4) with the screw (5) (Fig-2, 4-5).
5. Insert the assembled part into the plastic fastener (8) and fix well with the M5x12
screw (10). (Fig2, 6-7)
