Saxby Lighting Varone 55702 Instruction Leaflet

Recessed bricklight

Advertisement

Quick Links

Commissioning

• After connecting the supply cable to the terminal block,
replace the fascia using the 4 screws removed earlier.
• Insert the light into the housing until the spring
clips lock into place. Ensure the shade is pointing

Fitting/replacing bulbs

• The LED bulbs in this product are non replaceable
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could
damage the finish.

Recycling advice

Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.

Safety information

Live Voltages may be present in this unit even when turned off or when completely disconnected. For your safety,
always switch off the supply before changing lightbulbs, or cleaning.
The LED module is protected by a shade. The shade cannot be replaced, if the shade
becomes cracked or damaged, this fitting must be discarded.
www.saxbylighting.com
downwards to avoiding staring directly into the LEDs.
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use.
Iss.1 19032015
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
Varone Recessed Bricklight
55702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Varone 55702 and is the answer not in the manual?

Questions and answers

Summary of Contents for Saxby Lighting Varone 55702

  • Page 1 Commissioning Instruction leaflet • After connecting the supply cable to the terminal block, downwards to avoiding staring directly into the LEDs. replace the fascia using the 4 screws removed earlier. • Replace fuse or circuit breaker and switch on. Your • Insert the light into the housing until the spring light is now ready for use. Varone Recessed Bricklight clips lock into place. Ensure the shade is pointing 55702 Fitting/replacing bulbs • The LED bulbs in this product are non replaceable We recommend cleaning with a soft dry cloth.
  • Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before Knock out a suitable cable entry hole and pull the supply installation of a new product. Before removing the cable though. existing fitting, carefully note the position of each set Warning of wires. • Fit the housing into position and secure. This surround may be cemented in position. Wait until • The product comes with a housing unit that must be the cement has set before continuing with the This is a Class 1 product and must be earthed. If replacing an existing fitting, make a careful note of fitted into the hole prior to any wiring taking place. installation. the connections. • Cut the mounting hole for the unit taking care not Please read these instructions carefully before • Unscrew the 4 screws around the fascia to access...
