Replacing the Belts and Brush Rolls
Scan the QR code for a how-to video.
1. Unplug machine and remove
both tanks. While reclined, lay
machine on its front.
4. If flat belt is broken, place
a new belt around red pulley.
Stretch belt toward back of
machine and around metal
shaft.

Troubleshooting

Visit support.BISSELL.com or scan the QR code with your
smartphone camera for troubleshooting.
Note: Any other servicing should be performed by an authorized
service representative.

Warranty

Limited 5-year warranty, may vary by state. Visit support.BISSELL.com or call 1-800-237-7691
for complete warranty information.
WARNING
steam-cleaning or when the nozzle is heated.
2. Remove belt cover. Use
Phillips-head screwdriver to
remove three screws.
5. If brush roll belts or brush
roll assembly is broken, replace
with new brush roll assembly.
To reduce the risk of injury, do not touch the steam cleaning nozzle or adjacent surfaces when
3. Use Phillips-head
screwdriver to remove two
screws. Then remove brush roll
assembly by unhooking belt.
6. Reinstall brush roll
assembly, making sure to loop
belt over the shaft. Reinstall
belt cover.
BISSELL.com 11
