Three Modes of Cleaning
Visit support.BISSELL.com for how-to videos.
Startup
• This appliance is primarily a carpet cleaner with a steam-cleaning feature.
• Remove any solids and use a dry vacuum cleaner over area before using your deep cleaner.
• To prevent damage to Berber carpets, avoid repeated strokes in the same area. Before
cleaning area rugs, check the manufacturer's tag and test an inconspicuous spot on the rug for
colorfastness. Do not use on silk or delicate rugs.
• Stay off carpet until dry.
1. Plug into a properly
grounded outlet. Press power
button on handle to turn ON.
Pretreat with Steam
Loosen tough stains before removing with SteamWash Max Clean mode.
motor will shut off
in this mode.
1. Press mode button until
Pretreat icon is illuminated.
Icon will blink until heater is
ready to make steam.
2. Water heater will turn on. Machine defaults to Steamwash Max
mode with brush rolls and vacuum motor on. Foot icon will blink
and turn solid when heater is ready to make steam (<60 seconds).
2. Press recline pedal to
Pull trigger
recline machine.
to release steam
and move
machine forward and back
over stain for 20 seconds.
Brush rolls and vacuum
3. After steam pretreat, press
mode button to clean the stain
in SteamWash Max mode.
CONTINUED ON NEXT PAGE
BISSELL.com 5
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the REVOLUTION HYDROSTEAM 3423 Series and is the answer not in the manual?
Questions and answers
Spray hose not spraying solution
The spray hose on the Bissell REVOLUTION HYDROSTEAM 3423 Series may not be spraying solution due to several possible reasons:
1. Empty Clean Water Tank – Ensure the clean water tank has enough solution.
2. Clogged Hose or Nozzle – Check for blockages and rinse with warm water.
3. Unseated Tank – Make sure the clean water tank is properly installed.
4. Trigger Not Engaged – Ensure the spray trigger is being pressed correctly.
5. Air in the Hose – Prime the hose by holding the trigger until the solution flows.
If the issue persists, further troubleshooting may be needed.
This answer is automatically generated
Using Attachment with Trigger To Clean Steps
To clean steps with the attachment using the Bissell Revolution Hydrosteam 3423 Series:
1. Attach the Hose:
- Lift the accessory hose door on the front of the machine.
- Insert the hose until it clicks into place, ensuring the colored hose release clip faces outward.
2. Attach the Tool:
- Connect the desired cleaning tool (e.g., 2-in-1 Upholstery Tool or 3”/6” Tool) to the end of the hose.
3. Select Cleaning Mode:
- If using the 2-in-1 Upholstery Tool, switch between Wet and Dry Cleaning modes as needed.
4. Apply Cleaning Solution:
- Point the tool above the stain and press the spray trigger to dispense water and formula.
5. Scrub and Extract:
- Gently scrub the stain with the tool.
- Release the trigger and suction up the stain by moving the tool over the cleaned area.
6. After Cleaning Care:
- Empty and rinse the tool’s dirt bin if applicable.
- Allow it to dry completely before reinstalling.
Note: The hose and tool use only water and formula, not steam.
This answer is automatically generated
