Strobel 58 Series Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For the professional user
Für den professionellen Anwender
Operating Instructions
Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Dated:
Stand:
58
17
S p e z i a l m a s c h i n e n G m b H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 58 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Strobel 58 Series

Summary of Contents for Strobel 58 Series

  • Page 1 For the professional user Operating Instructions Für den professionellen Anwender Betriebsanleitung Class: Klasse: Model: Ausführung: Dated: Stand: S p e z i a l m a s c h i n e n G m b H...
  • Page 2 The sign of quality ou find the Strobel trademark on every Strobel machine leaving our works. And with good reason. This symbol is a guarantee of the high quality of our products. Quality which creates trust – trust in our technology, our service and, not least of all, in our good name.
  • Page 3 We wish you lots of success in your work with your new Strobel machine. S p e z i a l m a s c h i n e n G m b H...
  • Page 4 Boschstraße 16 D-82178 Puchheim Tel.: 089/80096-0 Fax: 089/80096-190 info@strobel.biz Maschinenklasse/Machine class: Serien-Nr./Serial No: Auftrags-Nr./Order Confirmation No: Lieferdatum/Delivery Date: Rechnungs-Nr./Invoice No: Rechnungsdatum/Invoice Date: Beanstandung/Complaint: Datum/Date Unterschrift/Signature: Bitte nicht vom Kunden ausfüllen/To be filled out by Strobel: Datum Bemerkung EXA: ETA: PROD: EXA:...
  • Page 5 BA_58_A17_220628_en.doc...
  • Page 6 BA_58_A17_220628_en.doc...

  • Page 7: Table Of Contents

    Operating instructions STROBEL Class 58-4D C o n t e n t s General notes on safety ......................5 General ............................5 Operating instructions ...................... 7 Class description, serial number and initial basis for description ........7 Range of application and intended use ................7 Technical data ........................
  • Page 8 Operating the machine......................25 General ..........................25 Switching on ........................25 Placing and removing the fabric - sewing process ............25 Sewing ..........................27 Padding (Fig. 6 and 7) ...................... 27 Problems during sewing and possible solutions............. 28 Machine maintenance ......................31 General ..........................

  • Page 9: General Notes On Safety

    General notes on safety Manuals and additional information can be found on the STROBEL website at: http://www.strobel.biz Every person in charge of setting up, operating, servicing and repairing the machine must first read and understand the operating instructions and particularly the safety instructions before starting up the machine.
  • Page 10 It is essential that you observe and follow these instructions as well as the generally valid safety regulations. Warning instructions given in the operating instructions that pertain to especially dangerous parts of the machine must be indicated at these positions using a safety symbol.

  • Page 11: Operating Instructions

    General Operating instructions Any person involved in the installation, operation, maintenance and repair of the machine must have read and understood the operating instructions and mainly the safety instructions before starting the machine. Class description, serial number and initial basis for description For side-referenced descriptions, the operating side of the machine is the starting base.

  • Page 12: Technical Data

    Technical data Empfohlene Nennstichzahl / 3200 min-1 Recommended rated speed Stichlänge / stitch length 5,0 - 8,0 mm (abhängig vom Nähmaterial / depend on fabric) Auslieferzustand / delivery condition 8,0 mm Obertransport / top feed Sägeverzahnung /saw toothing einstellbarer starrer Drücker für die verschiedenen Arbeitsgänge / adjustable fixed plunger for different applications...
  • Page 13 Technischer Auslieferzustand / delivery condition: Riemenscheibendurchmesser Maschine/ dw 80 mm machine pulley diameter Motor-Leistung min. / min. motor power 550 W Keilriemen-Profil / V-belt profile 10 x 6 mm Zahnriemenscheibe Maschine / Z = 38 toothed belt pulley/machine Zahnriemenprofil / toothed belt profile HTD 5M-9 Stichart / stitch type Einfaden-Kettenstich-Blindstich Typ 103 /...

  • Page 14: Installation And Putting Into Service

    Installation and putting into service Unpacking the machine Strobel machines are supplied either as complete units with head, stand and motor, or head with motor only, or the head only. Reel stand, rods and other accessories are packed into the packing.
  • Page 15 Fig. 1 A T T E N T I O N ! Before putting the machine into service make sure that the electric connecting data on the motor's name plate, mainly voltage and frequency, correspond to your electric network. A T T E N T I O N ! The machine must be oiled before first start.

  • Page 16: Sense Of Rotation

    Sense of Rotation The correct turning of the hand wheel is clockwise in line of vision on the hand wheel. Motor drive via V-belts 3.4.1 Tensioning the V-belt C A U T I O N ! Danger of injury! When checking the belt tension, switch off the machine at the mains.

  • Page 17: Positions Of The Machine

    3.4.2 Positions of the machine C A U T I O N ! Danger of injury! Danger of crushing fingers and needle through stitching as well as pulling in of parts of clothing. Keep fingers and hands away from moving parts when setting the position generator and checking the positions with switched- on machine.
  • Page 18 Machine with or without thread cutter: The machine requires a needle position and, depending on the sewing drive, possibly also a reference position. Reference (Fig. 4): The reference position must be set in such a way, that the point of the needle in the direction of the insertion stitch closes with the right (inner) edge of the needle slide plate.

  • Page 19: Motor Drive Via Toothed Belt

    Motor drive via toothed belt 3.5.1 Tensioning the toothed belt (Fig. 6) C A U T I O N ! Danger of injury! Switch off the machine at the mains when checking the belt tension. Do not operate the machine without belt guard. Otherwise Danger of crushing fingers, of injuries to the body or of pulling in of part of clothing.

  • Page 20: Positions Of The Machine

    3.5.2 Positions of the machine C A U T I O N ! Danger of injury! Danger of pulling in parts of clothing and of hair and danger of crushing fingers and stitching fingers with needles! When checking positions with switched-on machine keep fingers and hands away from moving parts.

  • Page 21: Instructions For Use

    Instructions for use Needles and threads The sewing quality can be influenced to a considerable extent by choosing the most suitable needles and threads for the material to be sewn. It is recommended to use controlled GROZ-BECKERT needles system 4669 EEO only. The machine is supplied with size 80/12 needles.

  • Page 22: Threading And Thread Course

    Fig. 8 Threading and thread course C A U T I O N ! Danger of injury! Switch off machine electrically and confirm that the machine is really in standstill position by operating the treadle for the motor control before threading. Otherwise there is a danger of injury from crushing and needle punctures.

  • Page 23: Thread Tension

    Thread tension Depending on thread and fabric quality, nature and thickness the thread tension is set by tension nut (1) (Fig. 9). Stitch depth regulator 4.5.1 General By means of the stitch depth regulator you can adjust the distance between the upper edge of the plunger and the needle radius, i.e.

  • Page 24: Digital Stitch Depth Indication

    4.5.3 Digital stitch depth indication On the stitch depth display (Fig. 11) the immersion height can be read off digitally. With frequently changing sewing matter thickness, this makes the finding of earlier settings substantially easier. Current supply is through a 9V battery located in the housing. To prevent premature discharging of the battery, the display should be switched off with the toggle switch on the housing during longer work pauses and when work is completed.

  • Page 25: Plunger Limit Stop

    Plunger limit stop 4.6.1 General (Fig. 12) C A U T I O N ! Danger of injury! For settings in the stitch plate area, switch off the machine electrically, and depress the motor switch pedal to make sure that the machine is truly switched off. Otherwise there is a danger of injury from crushing and needle punctures.

  • Page 26: Material Feed

    Material feed 4.7.1 General The fabric is fed by means of a rigid upper feed. The feed (stitch length) is adjustable in 4 steps from 5 to 8 mm. Standard equipment is a saw-teethed feed dog. 4.7.2 Setting the stitch length (Fig. 13) A T T E N T I O N ! Switch off machine electrically and make sure that the machine is really in standstill position by operating the treadle for the...
  • Page 27 Fig. 14 and Fig. 15) To switch from blind stitch to through stitch or vice versa, the plunger (1) is provided with a swiveling plunger (2). In Fig. 14 of the plunger (1) overlapping plunger (2) is pivoted backwards and out of action.

  • Page 28: Sewing Drive

    Sewing drive General: To drive the sewing machine, a compact motor with attachment to the upper part is provided. Precise positioning of the machine and operation of the electromechanical thread trimmer and pneumatic lifting requires the use of a needle-positioning motor. Please note the instructions available online.

  • Page 29: Operating The Machine

    Operating the machine General It is recommended to equip the machine with a pneumatic lifting device to facilitate machine handling C A U T I O N ! Danger of injury! Please observe the sewing area carefully during sewing. Otherwise there is a danger of injury from crushing and needle punctures.
  • Page 30 Fig. 16 BA_58_A17_220628_en.doc...

  • Page 31: Sewing

    Padding (Fig. 6 and 7) Class 58-4 is especially suitable for roll-padding both lapels, sewing in an upward direction (Strobel patent) because of their wide passage space. Padding a flap from bottom to top is more advantageous than the padding from top to bottom.

  • Page 32: Problems During Sewing And Possible Solutions

    Problems during sewing and possible solutions C A U T I O N ! Danger of injury! Switch off machine electrically and confirm that the machine is really in standstill position by operating the treadle for the motor control. Otherwise there is a danger of injury from crushing and needle punctures.
  • Page 33  Unintended skip stitching Possible reasons: wrong looper setting wrong setting of loop stroke/needle stroke, therefore insufficient loop formation (small/big) chaining finger damaged or not correctly set wrong setting of cloth retainer or cloth retainer pressure Solutions: operate machine manually, check the looper motion check the settings, re-set, if necessary, replace damaged parts change thread feed through thread take-up, if necessary ...
  • Page 34  Material feed problems (stitch length different from settings) Possible reasons: feed dog setting is not correct, material cannot be caught sufficiently. unsuitable feed dog toothing different pressures on the left and right hand feed plates feed plates lift is blocked material accumulation in the Stitch plate, mainly over cross seams seam or loop are caught by the feed dog unintended stitch length modification...

  • Page 35: Machine Maintenance

    Machine maintenance General C A U T I O N ! Danger of injury! Disconnect the machine from the mains and ensure that it is off by pressing the pedal for switching the Sewing drive. Otherwise there is a danger of injury from crushing and needle punctures.
  • Page 36 Fig. 19 BA_58_A17_220628_en.doc...
  • Page 37 Fig. 20 BA_58_A17_220628_en.doc...

  • Page 38: Lubricants

    Lubricants Only oil with a viscosity of 46cSt may be used. This lubricants can be obtained from us. 291.0107 Oil 0,5 litre Variable sewing tools C A U T I O N ! Danger of injury! Switch off machine electrically and confirm that the machine is really in standstill position by operating the treadle for the motor control.
  • Page 39 Cl. 58-4D Standard Optional Optional Stitch plate 7,0 mm opening 4,5 mm opening 6,0 mm opening 580.0089 580.0090 580.0091 Cloth retainer 188.0066 188.0072 188.0071 (included in 580.0091) (included in 580.0089) (included in 580.0090) Stitch formation Standard Feed dog 182.0185 BA_58_A17_220628_en.doc...

  • Page 40: Optional Extras

    Optional extras The following devices are available as optional extras and can be ordered together with the machine or as separate kits. Thread trimmer 798.0496 electromechanical thread trimmer Prerequisite here is use of the EFKA Kompakt DC 1200 with AB611 BA_58_A17_220628_en.doc...
  • Page 41 Und wir können noch mehr für Sie tun! Unser Lieferprogramm bietet für jede Branche und jegliche Anforderung genau die richtige Problemlösung. And we can do a lot more for you! Our range offers the correct problem solution for every branch and for all requirements. Für die Polster- Für die Bekleidungs- Für die Schuh-...
  • Page 42 Then phone, write or simply come and see us. You can have further information about our products at any time, or experience the Strobel machines live in our show room. We’re looking forward to meeting you! S p e z i a l m a s c h i n e n G m b H...
