Strobel 58-4 Operating Instructions Manual

Professional sewing and stitching machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For the professional user
Für den professionellen Anwender

Operating Instructions

Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Dated:
Stand:
58
17
S p e z i a l m a s c h i n e n G m b H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 58-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Strobel 58-4

Summary of Contents for Strobel 58-4

  • Page 1: Operating Instructions

    For the professional user Operating Instructions Für den professionellen Anwender Betriebsanleitung Class: Klasse: Model: Ausführung: Dated: Stand: S p e z i a l m a s c h i n e n G m b H...
  • Page 2 The sign of quality ou find the Strobel trademark on every Strobel machine leaving our works. And with good reason. This symbol is a guarantee of the high quality of our products. Quality which creates trust – trust in our technology, our service and, not least of all, in our good name.
  • Page 3 Justify your trust. If you wish to profit from the performance and efficiency of your Strobel machine as long as possible, exact handling and thorough care is necessary. For this reason we kindly request that you read the operating instructions closely.
  • Page 5 BA_58_A17_161026_en...
  • Page 6 BA_58_A17_161026_en...

  • Page 7: Table Of Contents

    Device for changing from blind stitch to through stitch ......... 14 Lowering the material support arm to lubricate the machine (Fig. 2 and Fig. 3) ..................15 Padding instructions for Class 58-4 (Fig. 6 and 7) ........15 Thread trimmer (Fig. 8) ................. 16 4.8.1 Removing and remounting of the thread trimmer drive (Fig.
  • Page 8 Subject to change without prior notice Appendix Circuit diagrams Connecting Pneumatic: 259.00.27 Pneumatic circuit diagram cl. 58 259.10.27 Pneumatic construction circuit diagram cl. 58 Connecting digital display: 258.21.28 Electric connection diagram cl. 58 – digital display Connecting thread trimmer: 258.21.47 Electric connection diagram cl.

  • Page 9: General Notes On Safety

    General notes on safety Every person in charge of setting up, operating, servicing and repairing the machine must first read and understand the operating instructions and particularly the safety instructions before starting up the machine. Failure to comply with the following safety instructions can lead to bodily injury or damage to the machine.
  • Page 10 14. Warning instructions given in the operating instructions that pertain to especially dangerous parts of the machine must be indicated at these positions using a safety symbol. Warning instructions given in the operating instructions that pertain to special injury hazards for operating personnel or technicians must be indicated at these positions using a safety symbol.

  • Page 11: General

    General Technical data Number of stitches: Max mechanically admissible 3500 min Recommended rated speed 3200 min Machine pulley diameter dw 80 mm Motor power 400 W V-belt profile 10 x 6 mm Toothed belt pulley/machine Z=38 Toothed belt profile HTD 5M-9 Stitch length-upper feed 5 - 8 mm (depend on fabric)

  • Page 12: Starting Up. Lubricating And Cleaning Machine

    Longitudinal section of the machine, showing important lubrication points. Fig. 4 and Fig. 5 Views of device for changing from blind stitch to through stitch (Class 58-4). Fig. 6 and Fig. 7 Padding and the correct way to introduce the material into the machine.

  • Page 13: Instructions For Use

    Instructions for use Needles and Threads Needles: STROBEL 1669 E Astro, No. 80 – 110 (Usual needle size 90) Thread: Mercerized cotton (such as Gögginger padding yarn 80) G u a r a n t e e d r e m a r k ! This machine has been set and sewn off with genuine Strobel needles.
  • Page 14 Fig. 1 BA_58_A17_161026_en...
  • Page 15 Fig. 2 BA_58_A17_161026_en...
  • Page 16 Fig. 3 BA_58_A17_161026_en...
  • Page 17 Fig. 4 Fig. 5 Fig. 6 BA_58_A17_161026_en...

  • Page 18: Adjusting Stitch Length (Fig. 1)

    M (Fig. 1). (Click!) Device for changing from blind stitch to through stitch Class 58-4 ( Fig. 4 and Fig. 5) To change from blind stitch to through stitch the cloth bender or presser 181.00047 is equipped with a swiveling supplementary presser 181.0017.

  • Page 19: Lowering The Material Support Arm To Lubricate The Machine (Fig. 2 And Fig. 3)

    Fig. 2 and Fig. 3. Padding instructions for Class 58-4 (Fig. 6 and 7) Class 58-4 is especially suitable for roll-padding both lapels, sewing in an upward direction (Strobel patent) because of their wide passage space. Fig. 6 show how to pad a right lapel which is sewn from the bottom upwards, working from the lapel break towards the edge, so that the front part left of the material support arm can be guided over the table.

  • Page 20: Thread Trimmer (Fig. 8)

    Thread trimmer (Fig. 8) The blade of the thread trimmer is activated by a rotary magnet, to which an electric release control system (microswitch) is connected. This prevents the machine from starting when the blade is no longer in its inital position. Thus the release control system prevents a possible collision between blade and gripper.
  • Page 21 Fig. 8 BA_58_A17_161026_en...

  • Page 22: Adjustment (Fig. 8 And Fig. 9)

    4.8.2 Adjustment (Fig. 8 and Fig. 9) The thread trimmer drive must be inserted as far as it will go into the needle plate clamp. Swivel the drive backwards so that there is a gap of about 1 mm between the drive and the sewing head.

  • Page 23: Replacing The Knife (Fig. 8 And Fig. 9)

    The machine should be positioned in such a way as the pedal is stepped back that the distance between gripper and blade in cutting position is approx. 1 mm. For Strobel and EFKA controls, this corresponds to parameter 171, position P2E.
  • Page 24 259.00.44 Pneumatischer Schaltplan Kl. 58 Pneumatic circuit diagram cl. 58 1V10 0 Z 1 10bar max 6bar 195.0523 0 Z 1 Wartungseinheit service unit 1 V 1 3/2-Magnetventil "Lüftung" 3/2-solenoid-way valve "lifting" 1 V 10 Drosselrückschlagventil "Lüftung" throttle-non-return valve "lifting" 1 A 1 Zylinder "Lüftung"...
  • Page 25 259.10.44 Pneumatischer Bauschaltplan Kl. 58 Pneumatic construction circuit diagram cl. 58 Wartungseinheit service unit 293.0975 (293.0841) (293.0850) Magnetventil solenoid valve 293.0469 193.0658 193.0530 298.0179 293.0852 297.0170 1 V 1 P (R) 293.0850 Lüftung 193.0473 450 lg lifting 293.0469 298.0582 293.0850 293.0468 293.0470 195.0524...
  • Page 26 258.21.28 Elektrischer Anschlussplan Kl. 58 Digitalanzeige Electric connection diagram cl. 58 Digital display Steck-Adapter EA 9044 ws / wh socket adapter EA 9044 gn / gn br / bn 137kΩ 9 10 Widerstand resistor Klemmblock terminal block 5kΩ lin. Drehpotentiometer rotary potentiometer Kippschalter flip switch...
  • Page 27 258.21.47 Elektrischer Anschlussplan Kl. allg. Fadenabschneider Electric connection diagram cl. gen. Thread trimmer Fadenabschneider Thread trimmer Spule Kontakt (NC) (NO) Drehmagnet Laufsperre Spool Contact solenoid run inhibition Spannung/Voltage: + 24 VDC (FA in Ruhestellung = Strom/electricity: Kontakt geschlossen) (FA at rest = contact closed) Benennung/Description Kontakt Laufsperre...
  • Page 29 Und wir können noch mehr für Sie tun! Unser Lieferprogramm bietet für jede Branche und jegliche Anforderung genau die richtige Problemlösung. And we can do a lot more for you! Our range offers the correct problem solution for every branch and for all requirements. Für die Bekleidungs- Für die Schuh- Für die Polster-...
  • Page 30 Then phone, write or simply come and see us. You can have further information about our products at any time, or experience the Strobel machines live in our show room. We’re looking forward to meeting you! Spe zi a l ma s c hine n G m bH...
