Test Mode

Operation:
With a touchpad at one end, this is the time it took the swimmer to
make an initial turn, swim down the lane, turn at the other end, swim
back and complete the turn at the end with the touchpad.
With a touchpad at each end, this is the time it took the swimmer to
make an initial turn, swim down the lane and complete the turn at the
other end.
The clock displays the mid-race time until the clock is reset with a
double click from the Reset/Breakout input, or a start input.
Mode 16
The clock displays 16, indicating mode 16. It will then cycle through
a digit test. Note that the colons between the third, fourth and fifth
digits are never used, and will not light during the digit test.
Input ports can also be tested. When an input port receives a signal
the clock shows which input port was triggered, as shown:
Touchpad PAd
RJP rJP
Start StArt
Reset/Breakout rESET
15
