Start Reaction; Turn Speed - Colorado time systems QuickStart Pro User Manual

Start Reaction

Equipment required:
Set up:
Operation:

Turn Speed

Equipment required:
Set up:
Operation:
10
The clock displays the exchange time for 10 seconds, and then auto-
matically resets itself for the next exchange.
Mode 6
Start system or pushbutton, and touchpad for backstroke starts or
RJP for starting block starts. Optional pushbutton for reset.
Connect the start system or a pushbutton to the Start System input.
For backstroke starts, connect the touchpad to either Touchpad input.
For starting block starts, connect the RJP to the Relay Platform in-
put. If you would like to use a pushbutton to reset the clock after a
start has been recorded, connect a pushbutton to Reset/Breakout.
The clock displays 06, indicating mode 6. The numbers on the dis-
play go blank, leaving a colon and a decimal lit. The clock is waiting
for a start input. The start input starts the clock and the display
counts up in hundredths of a second for 2 seconds. All touchpad or
RJP inputs detected during this time are recorded, and the last one
recorded is displayed at the end of the 2-second window. Start reac-
tion times of .55 to .74 seconds are shown in green; .75 to 2.00 sec-
onds are shown in yellow; .54 seconds and below would be consid-
ered early starts and are shown in red.
The start reaction time (the difference between the start input and the
swimmer's departure) is displayed until the clock is reset with a dou-
ble click from the Reset/Breakout input, or a new start input.
If a start input is received and no RJP or touchpad input is detected
within 2 seconds, the clock will display "Err" in red.
Mode 7
Touchpad
Connect the touchpad to either of the Touchpad inputs.
The clock displays 07, indicating mode 7. The numbers on the dis-
play go blank, leaving a colon and a decimal lit. The clock is waiting
for a touchpad input (typically hand touch). All touchpad releases
detected during the next 3 seconds are recorded. The last one re-
corded (departure) is displayed at the end of the 3-second window,
showing the time it took for the turn (the difference between the
two).
