Breakout Time

Equipment required:
Set up:
Operation:
Start Reaction and

Breakout Time

Equipment required:
Set up:
Operation:
The clock displays the turn time for 10 seconds, and then automati-
cally resets itself for the next turn.
Mode 8
Start system, and breakout timer or pushbutton.
Connect the start system to the Start System input, and connect the
pushbutton or other breakout timer to the Reset/Breakout input.
The clock displays 08, indicating mode 8. The numbers on the dis-
play go blank, leaving a colon and a decimal lit. The clock is waiting
for a start input. The start input starts the clock and the display
counts up in hundredths of a second until a breakout input is de-
tected.
The breakout time (the difference between the start input and break-
out input) is displayed until the clock is reset with a double click
from the Reset/Breakout input, or until a new start input starts the
clock from zero.
Mode 9
Start system, breakout timer or pushbutton, and touchpad or relay
platform.
Connect the start system to the Start System input, and connect the
pushbutton or other breakout timer to the Reset/Breakout input. Con-
nect the touchpad to either Touchpad input or connect the RJP to the
Relay Platform input.
The clock displays 09, indicating mode 9. The numbers on the dis-
play go blank, leaving a colon and a decimal lit. The clock is waiting
for a start input. The start input starts the clock and the display
counts up internally for 2 seconds. All touchpad or RJP inputs de-
tected during this time are recorded, and the last one recorded is dis-
played at the end of the 2-second window. The clock continues to
count internally while it displays this time (start reaction time). Run-
ning time resumes on the display, until a breakout/reset input is de-
tected. The breakout time is then displayed until the clock is reset
with a double click from the Reset/Breakout input or a new start in-
put.
11
