Pace Clock With Lap Splits; Relay Exchanges - Colorado time systems QuickStart Pro User Manual

Pace clock with Lap
Splits
Equipment required:
Set up:
Operation:

Relay Exchanges

Equipment required:
Set up:
Operation:
Mode 4
Touchpad required; start system or pushbutton can be used to reset
the clock.
Connect the touchpad to either Touchpad input. If using a start sys-
tem or pushbutton for resetting the clock, connect the start system or
a pushbutton to the Start System input, or connect a pushbutton to
the Reset/Breakout input.
The clock displays 04, indicating mode 4. The display will flash, dis-
play :00, and begin counting up, showing the time as minutes, sec-
onds and tenths.
At each valid touchpad hit, the display shows the time of the
touchpad hit (lap split) in minutes, seconds and hundredths
(M:SS.HH). The running time is reset to 0 at the touchpad hit, and
continues running internally. Following the lap split display, the
clock will resume displaying the running time as minutes, seconds
and tenths.
A start input or a double click from the reset input will reset and start
the clock any time the running time is displayed.
Mode 5
Touchpad and relay judging platform (RJP).
Connect the touchpad to either Touchpad input. Connect the RJP to
the Relay Platform input.
The clock displays 05, indicating mode 5. The numbers on the dis-
play go blank, leaving a colon and a decimal lit. The clock is waiting
to record a relay exchange.
RJP input times are recorded, and the first touchpad hit is recorded.
For a legal relay exchange (the touchpad hit occurred before the re-
lay takeoff), the display shows the relay exchange time in seconds
and hundredths (SS.HH). Exchanges of .2 seconds and faster are
shown in green; exchanges of .21 seconds or greater are shown in
yellow. For an illegal relay exchange (the touchpad hit occurred after
the relay takeoff), the display shows the difference between the two,
in red, preceded by a minus sign. If no valid RJP input is detected
within 2 seconds of a touchpad input, "Err" will be displayed on the
clock in red.
9
