Canadian Timber Luna Sauna
Assembly Instructions
Requirements:
2 People (recommended)
7/16" (11mm) Socket
Rubber Mallet
Carpenter's Hammer
Carpenter's Level
Carpenter's Square
Cordless Drill (we supply the bit)
Phillips & Robertson Screwdrivers
•
2" (51mm) hole saw
Tape Measure
Step Ladder
View the assembly process
Manufactured by:
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
Advertisement
Related Manuals for leisurecraft Canadian Timber Luna
Summary of Contents for leisurecraft Canadian Timber Luna
- Page 1 7/16” (11mm) Socket Rubber Mallet Carpenter’s Hammer Carpenter’s Level Carpenter’s Square Cordless Drill (we supply the bit) Phillips & Robertson Screwdrivers • 2” (51mm) hole saw Tape Measure Step Ladder View the assembly process Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 2: Parts List
VENT1 Sauna Vent (Includes 2 Grills and Inside Slider LUHARDWARE Luna Sauna Hardware Package CT22LUMANUAL CT Luna Owners Manual 603004 2 Meter Sauna Door with Frame & Hinges Optional Heater Electric Heater Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 3 Canadian Timber Luna Sauna Assembly Instructions Index Parts List Base Preparation Sauna Assembly Bench Installation Electric Heater Installation (Option) Care &Maintenance Warranty Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 A solid base for your sauna is recommended and can be made from any of the following. Concrete Pad Wood Deck Crushed Stone Patio Stone/Paver Blocks It is recommended to build a base larger than required to provide a sitting area for cooling off during your sauna session Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 5 *Always ensure that you have the correct screw length so that there will be enough thread to hold, and especially, so that the screw does not go all the way through the material and come out the other side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 6 3” (76mm) screws, Continue adding staves in the same manner until you reach 8 staves on each side of the center stave and then move on to the next step. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 603009 (2) –2 holes , curved, one will have tongue on top and other will be on bottom. 603006 (12) –2 holes, groove on bottom, tongue on top. 602205 (2) – Threaded rods with nuts and washers. 603007 603009 603006 603009 603008 Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 8 (2 holes, groove on bottom, tongue on top) Insert the threaded rods through the holes in the rear wall staves. Repeat for the other side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 9 Place a washer and a nut on the top of the threaded rod and tighten. Repeat for all 4 ends of the threaded rods. Snap or cut off the excess threaded rod sticking out of the top ends. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 10 603009 (1) – 3 holes, notch for door, groove on bottom ,tongue on top, curved edges. 603004 (1) – Sauna Door 603014 (1) – 26 ½” x42-1/4” Window in Frame 603007 603009 603010 603004 603014 603012 603012 603010 603011 603013 603008 Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 11 Place the short piece with the curve on edge to start the other side of the door opening. (1 hole, groove on bottom, 1 curved outside edge, 1 flat edge on door side, and tongue on top) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 12 Place a washer and a nut on the bottom of the threaded rod and tap them up into the stave. Repeat for the other 2 threaded rods. Slide the window into the window groove. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 13 Using a rubber mallet, gently tap the staves to lock the tongue and groove into each other so they are tight. Insert 2 flat window side staves over the window. (2 holes, groove on bottom, flat ends and tongue on top) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 14 Tap the staves on the side of the walls to ensure they are all even then go back and give the nuts on the front and back walls a final tightening. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 15 Place the top center stave (concave on either side) over the front and back wall for temporary support. Start placing the side wall staves on either side and secure with 3” (76mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 16 Tap the “V” shape down until it is flat. Once the roof is flat, secure all the roof staves with 3” (76mm) screws in both ends of the staves. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 17 Repeat on the rear of the sauna. Once the rubber is stapled to both ends, use a utility knife to cut off any excess rubber. Mark the center of one of the trim pieces. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 18 Add another long trim piece above the corner trim pieces followed by the top corner trim pieces on either side. Install the last long trim piece in the same manner. Repeat for the back of sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 19 Use the included spacer blocks to properly align the next siding piece and secure with staples. Continue adding the siding pieces to the top of the sauna until 18 strips are placed. Repeat for the opposite side of the sauna, Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 20 2 –1 ½” (38mm) screws in the pre-drilled holes. Place the towel hook at desired location and secure with 4- 1 ½” (38mm) screws. Install the optional sand timer using 2 – 1 ½” (38mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 21: Bench Installation
Secure the bench to the bench bracket using 3 – 1 ½” (38mm) screws fastening between the slats to make the screws less visible. Repeat this for all 4 bench brackets. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 22 2 – 2” (51mm) screws for each of the bench supports. Follow the same steps to secure the bench supports to the floor using 2 – 2” (51mm) screws in each bench support. That completes the assembly of your 2 tier bench. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 23 2 – 2” (51mm) screws for each of the bench supports. Follow the same steps to secure the bench supports to the floor using 2 – 2” (51mm) screws in each bench support. That completes the assembly of your 2 tier bench. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 24 Due to the curved edge you will have to measure from a couple staves out from the wall where the floor is flat. Using the provided template, punch out the holes for your mounting bolts. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 25 Stand the 2 Assembled side pieces of the heater guard on edge with pre-drilled holes on the bottom. Screw heater guard support to either side using (2) – 1 ½” screws per side. Repeat for the bottom heater guard support. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 26 • This is recommended to burn off any oils impurities from manufacturing, and it also “cures” the woodwork. • All wiring should be installed according to the heater manufacturers instructions and by a licensed electrician. Do NOT use a G.F.I breaker Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 27 On the outside wall using 1 ½” screws, screw on the vent cover. Use a 1 ½” screw and attach the vent board on the inside of the sauna making sure it is tight but can still be turned. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 28 On the outside wall using 1 ½” screws, screw on the vent cover (Note that the holes under the heater on the inside do not get a cover) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 29: Care And Maintenance
This natural weathering will not harm the wood or impair the sauna’s performance. If you wish to retain the natural color of your Dundalk Leisurecraft Sauna, there are many cedar stains on the market and almost as many opinions as to which is best. -
Page 30: Warranty
This warranty is a parts only warranty and any service or labor costs would not be considered as part of the 3 year warranty. Purchaser Name: ________________________ Date: _______________ Purchased From: ________________________ Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
