Georgian Cabin Sauna with Porch
2 People (recommended)
Rubber Mallet
Carpenter's Level
Tape Measure
Cordless Drill
Phillips & Robertson Drill Bits
It is highly recommended to view the assembly video prior to starting assembly!
Click here to View the assembly process or scan the QR code below.
Manufactured by:
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
CTC88PW
Assembly Instructions
Requirements:
¼" (6mm) & ½" (13mm) Nut Driver Bit
Step Ladder
Grinder & Metal Cutting Disc
Carpenter's Hammer
Utility Knife
2" (51mm) hole saw
06/2024
Advertisement
Related Manuals for leisurecraft Canadian Timber Georgian CTC88PW
Summary of Contents for leisurecraft Canadian Timber Georgian CTC88PW
- Page 1 Phillips & Robertson Drill Bits 2” (51mm) hole saw It is highly recommended to view the assembly video prior to starting assembly! Click here to View the assembly process or scan the QR code below. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 2 Concrete Pad Wood Deck Crushed Stone Patio Stone/Paver Blocks It is recommended to build a base larger than required to provide a sitting area for cooling off during your sauna session Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 3 Secure the 2 outer floor joists on each side together with 4 – 3” (76mm) screws per side. Measure the distance from opposite corners to ensure the base is square, adjust if needed. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 Secure through the side of the floorboard using a 3” (76mm) screw into each joist. For stability and to keep the base square, you can temporarily secure a floorboard to the middle of the base. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 5 Repeat this process until you have installed 4 floorboards including the starter board. Locate and secure the board labeled “porch floor finisher” using the same process. Locate the first wall stave labeled “door”. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 6 Secure through the dado into the joist with 3” (76mm) screws. Secure the door stave to the floorboards from the inside with 3” (76mm) screws. To continue with the floorboards, locate the board labeled “floor starter”. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 Place the back wall starter stave. It is the same as the front wall starter stave without the door section cut out. Ensure the dados line up with the outer floor joist on either side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 8 If the walls are not sitting tight on the base, you can use a 5” (127mm) screw to pull them down tight to the base. Repeat on the side wall staves. Locate the 2 short pieces labeled “porch railing starter”. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 9 Place the short front wall board, tap them tight into the stave below and then secure through the dado groove with a 5” (127mm) screw. Repeat on opposite side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 10 3” (76mm) screw on the ends. Place another short front wall board, tap it tight into the stave below and then secure through the dado groove with a 5” (127mm) screw. Repeat on opposite side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 11 Place another short front wall board, tap it tight into the stave below and then secure through the dado groove with a 5” (127mm) screw. Repeat on opposite side. Repeat this method with a medium porch wall stave on either side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 12 Install the short side wall staves on both sides of sauna. Install the front wall staves labeled “window” on both sides ensuring the are the 4 row in the front wall. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 13 Install another back wall stave. Repeat on the side walls with 2 of the full-length side wall staves and then another back wall stave. Locate the 2 short pieces labeled “railing finisher”. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 14 Install a window wall board on both sides of the front wall and then another back wall stave. Continue building in this pattern alternating between building the back and front then the side staves. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 15 Place your windows onto the front wall and ensure the staves are fully inserted into the grooves. Slide the door in between the front wall staves ensuring the hinges face outwards. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 16 Install a back wall stave and secure with a 5” (127mm) screw in the notches. install one of the longer staves on each side in the same manner as in previous steps and then install another back wall stave. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 17 Place the top beam into the slots on the top of the triangle pieces. Use a rubber mallet to tap the top beam tight into the slots on the gable ends and secure with 5” (127mm) screws at both ends. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 18 Start placing the roof staves going up the roof and tap into each other, Secure with 2 - 3” (76mm) screws into each gable end. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 19 Place the side metal trim pieces on the sides of the roof and secure with the 12 of the included short black screws. Repeat for opposite side of sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 20 Place the next shingle ensuring it is flush and overlaps the ridge of the previous shingle. Secure using the included roofing screws into the 4 ridges closest to the edge of the sauna. Cut the last shingle to fit. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 21 When you reach the peak, use half width shingles. Repeat on the opposite side of the roof. Reveal the adhesive side of the M-seal and apply it to the inside edges of the ridge caps. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 22 Using a saw, cut off the tongue on the porch railings. Place the railing trim on the inside of the porch wall and secure with 2 – 2” (51mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 23 2 – 2 ” (51mm) screws in the pre-drilled holes. Install the inner door handle (large) horizontally at the desired height. Ensure the handle is level and secure using 2 – 2” (51mm) screws in the pre-drilled holes. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 24: Bench Assembly
Ensure the bench support is square and secure with 1 ¼” (32mm) screws from the bench into the support. Again, place the screws into between the bench slats to make them less visible. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 25 Mount the support board flush to the line of the bench and secure with 3 - 2 ½” (64mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 26 Line up the middle support and secure the bench to the supports and the supports to the floor and side wall in the same manner as previous steps. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 27 Use a 5” (127mm) screw in between the previously placed screws in the top of the door frame to pull in the middle of the Gable end. Install the optional Thermometer using a 1 ½” (38mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 28 Under normal conditions, a slight wash of the floor and benches with warm soapy water several times a year will maintain its cleanliness. Leisurecraft offers a sauna room cleaner that can be used pure or diluted at a 4-1 ratio. Simply spray and wipe! You can use a sheet of fine grit sandpaper or a low-pressure wash to remove more stubborn stains or for a deeper cleaning of the interior of your sauna.
- Page 29 This natural weathering will not harm the wood or impair the sauna’s performance. If you wish to retain the natural color of your Leisurecraft Sauna, Leisurectaft offers cedar sauna stains in 4 amazing colors, Espresso, Limestone Trail, Onyx Gem and Pickled White in convenient 1-gallon pails.
-
Page 30: Warranty
WARRANTY Leisurecraft warrants our Canadian Timber Collection Saunas against defects in materials and workmanship under normal/residential use for a period of three (3) years, as applicable, from the date of receipt of the product by the original end-user consumer. This warranty does not apply to normal wear and tear and/or natural weather conditions.
