11/2024
Canadian Timber
Serenity/Tranquility MP Barrel Sauna
Assembly Instructions
Requirements:
2 People (recommended)
Phillips & Robertson Drill Bits
¾" (19mm) Wrench/Nut Driver Bit
2" (51mm) hole saw
Rubber Mallet
Step Ladder
Carpenter's Level
Utility Knife
Tape Measure
Adjustable Wrench
Cordless Drill
7/16" (11mm) Socket
Carpenter's Hammer
Staple Gun
Jigsaw
5/16" (8mm) Nut Driver Bit
¾" (19mm) Spade Bit
Caulking Gun
Manufactured by:
tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com
Advertisement
Related Manuals for leisurecraft Canadian Timber Tranquility MP
Summary of Contents for leisurecraft Canadian Timber Tranquility MP
- Page 1 Rubber Mallet Step Ladder Carpenter’s Level Utility Knife Tape Measure Adjustable Wrench Cordless Drill 7/16” (11mm) Socket Carpenter’s Hammer Staple Gun Jigsaw 5/16” (8mm) Nut Driver Bit ¾” (19mm) Spade Bit Caulking Gun Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 2 Some details between this installation manual and the video may not be exactly same as Leisurecraft is continually trying to improve the quality of our products and ease of assembly. Please refer to this installation manual for the latest version.
- Page 3 Bench Installation Electric Heater Installation (Option) Wood Heater Installation (Chimney out the top) (Option) Wood Heater Installation (Chimney out the back wall) (Option) Asphalt Shingle Roof Installation Metal Roof Installation Care &Maintenance Warranty Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 4 A solid base for your sauna is recommended and can be made from the following. Concrete Pad Wood Deck Crushed Stone Patio Stone/Paver Blocks It is recommended to build a base larger than required to provide a sitting area for cooling off during your sauna session Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 5: Barrel Assembly
½”(14cm) from the end of the stave to the edge of the cradle. Secure the stave with a 3” (76mm) screw. Ensure that the stave is square and add 3 more 3” (76mm) screws into each corner of the cradle. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 6 Repeat at opposite end. Place the back bottom wall panel centered into the groove at the rear of the sauna and ensure it is level. Use a rubber mallet to tap into place if required. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 7 * Once past the middle point of sauna, nails should no longer be needed. Place the middle back wall panel onto the bottom panel and secure with 2 ½” (64mm) screws in the pre drilled holes. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 8 Continue adding staves on both sides until you get close to the height of the back wall. Place the window support piece onto the back wall. Ensure the curve follows the curve off the wall. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 9 2 ½” (64mm) screws. Place the door panel into the front groove of the Sauna. Using a level and rubber mallet, tap the door until it is centered and level. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 10 This is temporary and will be removed later. Repeat the process on the other side with the second Glass wall panel Place 9 more staves onto one side of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 11 Wedge the top center stave (concave on both sides) with the last stave, to create a “V” shape. Pre-assemble the front and back bands and thread the nut on just enough to hold it together. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 12 Ensure the band is 2” (51mm) from the edge of the sauna all the way around. Repeat for the front of the sauna. Again, ensure the front band is 2” (51mm) from the edge of the sauna all the way around. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 13 Ensure all fasteners are the same height. Place this band directly over the front wall panel making sure it is even all the way around the sauna. Tighten the band tapping the staves ensuring the staves are even. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 14 • In rare instances, your sauna staves will be too tight not allowing the staves to settle into the correct position and you will need to make the top stave narrower. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 15 Now screw the other side of the top stave back to the other half top stave and it should now make a “V” shape when wedged with the last stave on the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 16 Now screw the 2 cut pieces of the top stave back together. Reinstall the top stave and it should now make a “V” shape when wedged with the last stave on the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 17 Remove the temporary front wall support pieces from either side. Now finish screwing in the screws that we started earlier into the cradles. Repeat this process for the screws inside the sauna as well. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 18 Canadian Timber Serenity/Tranquility MP Barrel Sauna Assembly Instructions Barrel Assembly Use the caulking to seal the seams on the outside of the rear window. Repeat on the outside of the front half moon windows. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
-
Page 19: Bench Installation
Ensure the floor pieces are level. Once level, Secure the floor with 1 ½” (38mm) screws in the 4 corners of each floor piece screwing between the floorboards so the screws are not as visible. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com... - Page 20 Place 2 – 1 ½” (38mm) screws into the pre-drilled holes on each bench bracket. Line the bracket up with the support on the bottom of the bench and secure it with the pre-placed screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 21 Secure the wall support on its edge to the porch seat with 2- 3” (76mm) screws. Add 2- 3” (76mm) screws on the inside of the wall support to make mounting easier. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 22 Use a 3” (76mm) screw to go through the sauna stave into the front of the bench bracket. Repeat for porch bench on other side. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 23 Place the towel hook at desired location and secure with 4- 1 ½” (38mm) screws. Install the optional sand timer using 2 – 1 ½” (38mm) screws. Ensure it can rotate without hitting the wall. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 24 Transfer the measurements to the back wall of sauna. Ensure the heater will be centered between the benches. Install the two ¼" x 1 ½" (6mm x 38mm) hex head lag screws (supplied with the heater) into the holes. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 25 (2) – 1 ½” (38mm) screws per side. Repeat for the bottom heater guard support. Place 2- 2 ½” (64mm) screws into the pre-drilled holes on either side of heater guard to prepare for mounting. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 26 “cures” the woodwork. • All wiring should be installed according to the heater manufacturers instructions and by a licensed electrician. • Do NOT use a G.F.I breaker Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 27 Install floor heat shield against back wall centered between the benches. Place the rear wall heat shield and secure with 6 – 1 ½” (38mm) screws through the drilled holes. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 28 On the top of the sauna, measure 12” (305mm) from the end of staves. From the mark, make an 8” (203mm) circle. Cut the circle out with a jigsaw. Place the long chimney piece onto the stove. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 29 Lift the boot out of the way and apply the included roof sealer on the inside of the outline. Pull the boot back down and secure with the included self-sealing roofing screws 2-3” (51mm to (76mm) ) apart. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 30 Attach the support strap around the 2 chimney pipes and tighten up. Insert the short chimney piece into the thick chimney piece, followed by the cap piece. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 31 Only go half way through to prevent splintering and drill the remainder from the other side of wall. Using 1 ½” (38mm) screws, screw on the vent cover. (note that the vent guard only goes on the outside.) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 32 The assembly of your wood stove with chimney out the top is now complete. Enjoy your sauna! Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 33 Fasten the stove handle onto the stove door With the screws provided. Remove the screw on the back of stove and remove the back flap. Measure the height to the middle of the opening on the back of stove. (22”) (56mm) Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 34 From the mark, make an 8” (203mm) circle. Cut out the circle with a jigsaw. Install floor heat shield against back wall centered between the benches. Bring in stove and place it on the floor heat shield. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 35 Ensure the rear wall heat shield is level and secure with 6 – 1 ½” (38mm) screws through the drilled holes. Remove the nuts and bolts from the chimney support. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 36 Attach the support strap around the 2 chimney pipes and tighten up. Attached assemble chimney pieces to the “T” coming out the back of the sauna. Attach a support strap around the connection and tighten up. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 37 Ensure that it is level. Overlap the top half of the exterior chimney shield and secure with provided screws. Below the bench support on the back wall, mark the vent hole position. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 38 Use a 1 ½” (38mm) screw and attach the vent board on the inside of the sauna making sure it is tight but can still be turned. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 39 Install a support at 42” (107cm) high at the other end of the sauna. Install another one in the middle of the sauna and 1 more centered between these 2. This will make 6 supports across the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 40 Repeat for the opposite side of the sauna. Peel the film off the back of the ice & water shield. Place it flush to the bottom of the support boards and secure it with roofing nails on the ends. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 41 Tack it down with roofing nails. Continue this process until all the ice & water shield strips are placed. Cut off the excess ice & water shield from each end. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 42 The center trim piece may have to be cut to make it fit. Begin placing the shingles on the roof and secure with roofing nails. Continue adding shingles along this row to the back of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 43 Continue adding shingles in the same manner to the back of the sauna,. When you get to the 4 row, start the row with a full shingle. Continue this pattern until you get to the top center of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 44 Install the trim pieces to the back of the sauna in the same manner as the front securing with 1 ½” (38mm) screws. Again, the center trim piece may have to be cut to fit. Your Asphalt roof is now complete! Enjoy! Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 45 Secure with staples at the top and bottom of each strip of ice & water shield. Repeat on other side ensuring pieces overlap at the top of the sauna, Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 46 Center one of the trim pieces at the bottom on the front of the sauna. Raise it ½” (13mm) and secure it with 3 – 1 ½” (38mm) screws. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 47 It may be necessary to mark and cut the final trim piece to fit. Repeat for the rear of the sauna. Carefully remove the metal roofing from the packaging. Place 2 panels on to the top of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 48 Place the next panel and ensure the bottom ridge of the previous panel overlaps the top ridge of the bottom panel. Secure with 5 self-sealing roofing screws into the top and bottom ridges. Repeat on opposite side of the sauna. Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 49 Place a final self-sealing screw into the center of the roof. Add more screws into any of the ridges if necessary. The assembly of your metal roof is now complete! Watch the metal roof assembly video here! Metal Roof Installation Manufactured by: tel: 888-923-9813 | info@leisurecraft.com| web: www.leisurecraft.com...
- Page 50 Under normal conditions, a slight wash of the floor and benches with warm soapy water several times a year will maintain its cleanliness. Leisurecraft offers a sauna room cleaner that can be used pure or diluted at a 4-1 ratio. Simply spray and wipe! You can use a sheet of fine grit sandpaper or a low-pressure wash to remove more stubborn stains or for a deeper cleaning of the interior of your sauna.
- Page 51 This natural weathering will not harm the wood or impair the sauna’s performance. If you wish to retain the natural color of your Leisurecraft Sauna, Leisurecraft offers cedar sauna stains in 4 amazing colors, Espresso, Limestone Trail, Onyx Gem and Pickled White in convenient 1-gallon pails.
-
Page 52: Warranty
WARRANTY Leisurecraft warrants our Canadian Timber Collection Saunas against defects in materials and workmanship under normal/residential use for a period of three (3) years, as applicable, from the date of receipt of the product by the original end-user consumer. This warranty does not apply to normal wear and tear and/or natural weather conditions.
