- Page 1 Getting Started Type 2202 UltraView Ultrasound Systems BG0411-B English September 2013...
-
Page 2: Connect Transducers
Pull back on plug locking mechanism (collar). Caution: Never unplug system from wall while it is running! Remove plug from socket. Turn off system and wait for light on switch to go out before unplugging. Getting Started with UltraView 2202 • BG0411-B • September 2013... -
Page 3: Enter Patient Information
Select Pro Package and Transducer Pre- Enter Patient Information set (Diagnostic Setup) Press [r ID]. Patient window opens. Press [ c ]. Enter patient data. Use tab key to move from field to field. Select Pro Package and Diagnostic Setup. Click OK. - Page 4 Getting Started with UltraView 2202 • BG0411-B • September 2013...
-
Page 5: Frequently Used Keys
Frequently Used Keys Resolution: Increases resolution (decreases scanning 1. ID: Opens Patient window to start examination. frame rate) or vice versa in B-mode or Color mode. 2. Transducer/Application: Press to select Pro Package or Diagnostic Setup. requency: Changes MHz. 3. Gain: Brighter/Darker. Basic Measure: Activates cursors for basic measurement. - Page 6 Click Export and Copy to USB (without Patient ID) or Copy to USB. Click magnifying glass. Little frame around it turns blue. Document is displayed in the scan area. Click USB Eject to remove memory device. Getting Started with UltraView 2202 • BG0411-B • September 2013...
- Page 7 Copy to CD/DVD When you click Copy to CD/DVD, the selected images are Insert a CD or DVD into DVD drive. NOT copied immediately to a CD or DVD. They are copied to Click Burn CD. a staging area. To copy: Click each image to be copied.
- Page 8 P Shortcut Keys F Shortcut Keys P2: t F8: Report F10: Add pointer arrow to image Getting Started with UltraView 2202 • BG0411-B • September 2013...
-
Page 9: Your Notes
Your Notes Getting Started with UltraView 800 2202 • BG0411-B • September 2013... - Page 10 UltraView 2202 Advanced User Guide contains detailed information for the advanced user. www.bkmed.com This guide is also available on the BK Medical website. Please go to the Customer Service section to download user manuals. If you have comments about the user documentation, please write to us at info@ bkmed.dk.
