Summary of Contents for BK Medical 8822
- Page 1 User Guide Type 8822 Vascular Transducer 8822 English BB2018-B June 2012 For Professional Users Only...
- Page 2 If you receive an email message from us asking for your feedback, we hope you will be willing to answer some questions about your experience buying and using our products. Your opinions are important to us. You are of course always welcome to contact us via your BK Medical representative or by contacting us directly.
-
Page 3: Table Of Contents
Contents Introduction ............5 Indications for Use . -
Page 5: Introduction
Introduction This is the user guide for Vascular Transducer Type 8822 and must be used together with Care, Cleaning & Safety which contains important safety information. Indications for Use The 8822 is a linear 3-9 MHz vascular transducer, which is designed for deep vein and peripheral vascular examinations. -
Page 6: General Information
Service and Repair WARNING Service and repair of BK Medical electromedical equipment must be carried out only by the manufacturer or its authorized representatives. BK Medical reserves the right to disclaim all responsibility, including but not limited to responsibility for the operating safety, reliability and performance of equipment serviced or repaired by other parties. -
Page 7: Cleaning And Disinfection
Cleaning and Disinfection To ensure the best results when using BK Medical equipment, it is important to maintain a strict cleaning routine. Full details of cleaning and disinfection procedures can be found in Care, Cleaning & Safety that accompanies this user guide. A list of disinfectants and disinfection methods that the transducer can withstand are listed in the Product Data sheet. -
Page 8: Using The Transducer Control Button
Puncture and Biopsy Facilities WARNING It is essential for the patient’s safety that only the correct needle guide is used with Type 8822. Never use unauthorized combinations of transducers and needle guides or other manufacturers’ needle guides. Needle Guide UA1239 The UA1239 needle guide (Figure 3) is designed for guiding puncture and biopsy when used with Type 8822 (see Figure 4). - Page 9 Lock the swing arm into position at the neck end of the transducer. An audible click indicates when the needle guide is securely attached. Figure 4. The needle guide mounted on Type 8822. WARNING Ensure the bracket is positioned correctly.
-
Page 10: Performing Puncture And Biopsy
Move the transducer until the puncture line transects the target. Insert the needle and monitor it as it moves along the puncture line to the target. The needle tip echo will be seen as a bright dot on the screen. June 2012 8822 User Guide (BB2018-B) -
Page 11: Cleaning After Puncture And Biopsy
When performing a biopsy, always make sure that the needle is fully drawn back inside the needle guide before moving the probe. Figure 5. Puncture lines for UA1239 on Type 8822. Cleaning after Puncture and Biopsy If biological materials are allowed to dry on the transducer or needle guides, disinfection and sterilization processes may not be effective. - Page 12 June 2012 8822 User Guide (BB2018-B)
- Page 14 LEGAL MANUFACTURER : BK Medic al ApS , Milepa rken 34, 2730 Herlev, Denma rk. Tel.: +45 44528100 Fax : +45 44528199 E mail: info@bkmed.dk...
