BUTTON
Power / Energy:
• Displays power levels and the associated parameters (power factor, dis-
placement and tangent)
• Energy monitoring
• Four quadrant measurement to discern source/load active energy and induc-
tive/capacitive reactive energy

Control Features

1
2
3
4
5
1. Over molded protective housing
2.
LCD Display
3. Six function buttons (yellow)
4. Four function buttons (see chart, left)
5. ON/OFF button
6. Four current inputs and five voltage inputs

Connection Terminals

L1/A
1. Four (4) current inputs on the top of the instrument to enable the use of current sensors
(MN, SR, AmpFlex
2.
Five (5) voltage inputs.
3. Insertion locations for the current and voltage color-coded ID markers.
?
1
L2/B L3/C N/D
, MiniFlex , MR, SL and J93 probes).
® ®
DESCRIPTION
7. USB port
8.
Input for external power supply
and battery charging
9. Confirm/Enter button
10. Navigation buttons
11.
Six mode buttons (see chart, left)
2
E/GND
L2/B
L1/A L3/C
N/D
1000V CAT III 600V CAT IV
6
7
8
9
10
11
3
