  • Page 1 User Manual ENGLISH AC Current Oscilloscope Probe Model MN261 CURRENT MEASUREMENT PROBE E N G L I S H WITH AEMC INSTRUMENTS ®...
  • Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
  • Page 3 For recalibration, please use our calibration services. Refer to our repair and calibration section at www.aemc.com. Serial #: Catalog #: 2115.82 Model #: MN261 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux , Inc. ®...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ..............5 1.1 RECEIVING YOUR SHIPMENT ..........6 1.2 ORDERING INFORMATION ............. 6 1.2.1 Accessories and Replacement Parts ......... 6 2. PRODUCT FEATURES ............7 2.1 DESCRIPTION ................7 2.2 COMPATIBILITY ................ 7 2.3 CONTROL FEATURES ............. 8 3.

  • Page 5: Introduction

    Example: hardwired equipment in fixed installation and circuit breakers. CAT II corresponds to measurements performed on circuits directly con- nected to the electrical distribution system. Example: measurements on household appliances and portable tools. AC Current Oscilloscope Probe Model MN261...

  • Page 6: Receiving Your Shipment

    Save the damaged packing container to substantiate your claim. 1.2 ORDERING INFORMATION AC Current Oscilloscope Probe Model MN261......Cat. #2115.82 ncludes user manual and a product warranty and registration card. 1.2.1 Accessories and Replacement Parts Adapter - BNC (Female) to 4 mm Banana (Male) 600 V CAT III ............

  • Page 7: Product Features

    The probe connects directly to an oscilloscope through an insulated coax- ial cable with an insulated BNC. 2.2 COMPATIBILITY The Model MN261 is compatible with any analog or digital oscilloscope or other voltage-measuring instrument which has the following features: • BNC input connector •...

  • Page 8: Control Features

    Maximum dimension of conductor: 0.78 in (20 mm) Two position switch 6.5 ft (2 m) output cable Arrow indicates direction of current flow. Current flows in a positive direction when it travels from supply to load. AC Current Oscilloscope Probe Model MN261...

  • Page 9: Specifications

    40 Hz to 1 kHz: 10 % of mV output (1 to 10) kHz: 15% of mV output Range 200 A: 40 Hz to 1 kHz: 3% of mV output (1 to 10) kHz: 12% of mV output AC Current Oscilloscope Probe Model MN261...

  • Page 10: Mechanical Specifications

    EN 61010-2-032. Common Mode Voltage: 600V, CAT III, Pollution Degree: 2 Electromagnetic Compatibility: Emission and immunity in an industrial environment according to the stan- dard EN61326-1. *Specifications are subject to change without notice AC Current Oscilloscope Probe Model MN261...

  • Page 11: Typical Response Curves

    -10.00 10.00 100.00 1000.00 10000.00 100000.00 Frequency in Hz Phase Shift vs. Frequency 15.00 100 A 10.00 200 A 5.00 0.00 -5.00 -10.00 -15.00 -20.00 -25.00 10.00 100.00 1000.00 10000.00 100000.00 Frequency in Hz AC Current Oscilloscope Probe Model MN261...
  • Page 12 -30.00 10.00 100.00 1000.00 10000.00 100000.00 Frequency in Hz Phase Shift vs. Frequency 40.00 10 A 30.00 20 A 20.00 10.00 0.00 -10.00 -20.00 -30.00 -40.00 10.00 100.00 1000.00 10000.00 100000.00 Frequency in Hz AC Current Oscilloscope Probe Model MN261...

  • Page 13: Operation

    Before measuring insulation resistance, confirm that the sample is fully • Connect the Model MN261 to the proper input channel on the oscilloscope. • Begin with the least sensitive range on the current probe (10 mV/A).

  • Page 14: Maintenance

    Lubricate the jaws mating surfaces with a light oil. Do not use chemicals containing benzine, benzene, toluene, xylene,  acetone, or similar solvents. Do not immerse the probe in liquids or use abrasive cleaners.  AC Current Oscilloscope Probe Model MN261...

  • Page 15: Repair And Calibration

    Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® Phone: (800) 343-1391 (Ext. 351) Fax: (603) 742-2346 E-mail: techsupport@aemc.com www.aemc.com AC Current Oscilloscope Probe Model MN261...

  • Page 16: Limited Warranty

    Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360) Fax: (603) 742-2346 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument AC Current Oscilloscope Probe Model MN261...
  • Page 17 NOTES:...
  • Page 18 NOTES:...
  • Page 19 NOTES:...
  • Page 20 02/23 99-MAN 100144 v11 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: (603) 749-6434 • (800) 343-1391 • Fax: (603) 742-2346 www.aemc.com © Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ® ®...
