Performance Verification
4-48
d. Set the oscilloscope controls as follows:
Push the Default Setup (front).
Vertical . . . . . . . . . . . . . . . . . . . . . . . . . CH1 and CH2
CH1 coupling . . . . . . . . . . . . . . . .
CH1 scale . . . . . . . . . . . . . . . . . .
CH1 input impedance . . . . . . . . . .
CH2 scale . . . . . . . . . . . . . . . . . .
CH2 input impedance . . . . . . . . . .
Horizontal
Sweep . . . . . . . . . . . . . . . . . . . . .
Trigger
Source . . . . . . . . . . . . . . . . . . . . .
Coupling . . . . . . . . . . . . . . . . . . . .
Slope . . . . . . . . . . . . . . . . . . . . . .
Level . . . . . . . . . . . . . . . . . . . . . .
Mode . . . . . . . . . . . . . . . . . . . . . .
e. Set the function generator as follows:
Function . . . . . . . . . . . . . . . . . . . . . . . . Pulse
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . Continuous
Parameter
Frequency . . . . . . . . . . . . . . . . . .
Amplitude . . . . . . . . . . . . . . . . . . .
Offset . . . . . . . . . . . . . . . . . . . . .
Output . . . . . . . . . . . . . . . . . . . . . . . . . Off
2. Set the AWG500–Series Waveform Generator and load the waveform file.
a. Push UTILITY (front-panel)!System (bottom)!Factory Reset
(side)!OK (side).
b. Push SETUP (front-panel)!Run Mode (bottom)!Triggered (side).
c. Load the TRIG.WFM file.
Refer to Loading Files on page 4–15 for file loading procedures.
3. Push the RUN and CH1 OUT buttons.
The LEDs above the RUN button and CH1 output connector are on.
DC
500 mV/div
50 W
2 V/div
1 MW
2 ms/div
CH1
DC
Positive
+100 mV
Auto
100 Hz
1.0 V (2 V in open circuit)
(Adjust such as a pulse 4.65 V in
amplitude referenced to ground)
