Matrix II Wi-Fi
4. NETWORK CONNECTION MODES FOR MATRIX-II Wi-Fi DEVICE
Wi-Fi network connection parameters must be set up to operate the device in network mode.
When configuring the device, please note that Matrix II Wi-Fi device actually consists of three
functional modules: integrated reader, ACS controller and Wi-Fi network connection module.
The network module provides Wi-Fi connection of the device to facility's local network and
establishes connectivity with local PC running ACS control software to manage access control
functions (keys database management, definition of access rights, reading events from events
buffer, etc.).
There are three modes of control software connection:
- WEB connection mode. In this mode, the connection module connects to a control Web server
on the Internet, and the device is managed via a Web site (for example, Cloud ACS solution
www.guardsaas.com);
- Server connection mode. In this mode, the connection module is listening for TCP/IP calls from
the PC running control software (for example, GuardCommander, GuardLight, or Avantgarde
[Авангард]);
- Client connection mode. In this mode, the connection module attempts to connect to control
software via TCP/IP. To configure this mode, provide the IP address and port number of a remote PC
running the control software (for example, GuardLight, Avantgarde [Авангард], or Zproxy server).
Wi-Fi
Wi-Fi
Internet
DB
