WV-CS5S
Precautions
• Installation work requires technique and experience.
• Failure to observe this may cause injury or damage to the product.
• Be sure to consult the dealer.
Mounting procedures
Read along with the Installation Guide of the camera body.
Step 1
Connect the cables to the camera, and fix them to the ceiling. (Refer to the Installation Guide of the camera in use.)
Step 2
Remove the bottom decorative cover, and attach the dome cover to the top decorative cover.
Decorative cover (Top)
Decorative cover (Bottom)
• The decorative cover (Bottom) is not used.
• The decorative cover is secured with hooks at 3 points.
The dome cover is also secured with the same hooks.
WV-CS5C
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
WV-CS5S is a smoke type, WV-CS5C is a clear type.
Remove
Operating Instructions
Included Installation Instructions
Dome Cover
WV-CS5S
Model No.
WV-CS5C
Match the markings.
Dome cover
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for i-PRO WV-CS5S
Summary of Contents for i-PRO WV-CS5S
- Page 1 WV-CS5C Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. WV-CS5S is a smoke type, WV-CS5C is a clear type. Precautions • Installation work requires technique and experience. • Failure to observe this may cause injury or damage to the product.
- Page 2 Step 3 Remove the protective sheet from the lens surface of the camera. Step 4 Align the "|" mark of the decorative (Top) and the arrow mark of the camera body, and insert the cover from the bottom. After inserting the decorative cover, rotate it clockwise when looking at it from underneath by 2 steps to engage the cover by pushing it up as shown in the drawing below.
