i-PRO WV-S71300-F3 Basic Information

Hide thumbs Also See for WV-S71300-F3:

Advertisement

Quick Links

Download this manual
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for instal-
lation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use", "Parts and
functions" and "Detail specifications".
• Operating Instructions (Refer to the link on the following support website): Explains how to
perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/documentation-database
"<Control No.: C****>" used in these documents should be used to search for information on our technical
information website (https://i-pro.com/global/en/surveillance/training-support/support/technical-information)
and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
WV-S71300-F3
Model No.
Network Camera

Advertisement

loading

Related Manuals for i-PRO WV-S71300-F3

Summary of Contents for i-PRO WV-S71300-F3

  • Page 1 “<Control No.: C****>” used in these documents should be used to search for information on our technical information website (https://i-pro.com/global/en/surveillance/training-support/support/technical-information) and will guide you to the right information. • microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.

  • Page 2: Table Of Contents

    Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Parts and functions ........................8 Troubleshooting ........................... 10 Detail specifications ........................11...

  • Page 3: Limitation Of Liability

    IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:...

  • Page 4: System Requirements For A Pc

    System requirements for a PC CPU: Intel ® Core Processor family ® - Intel Core i5-6500 or faster - Intel ® Core i7-6700 or faster recommended Memory: 4 GB (2 GB x 2, Dual Channel) or more recommended. Network interface: 10BASE-T/100BASE-TX 1 port Audio interface: Sound card (when using the audio function)

  • Page 5: Network Security

    Network security As you will use this unit connected to a network, your attention is called to the following security risks. A Leakage or theft of information through this unit B Use of this unit for illegal operations by persons with malicious intent C Interference with or stoppage of this unit by persons with malicious intent It is your responsibility to take precautions such as those described below to protect yourself against the above network security risks.

  • Page 6: Precautions For Use

    Precautions for use When the product is accessible from the Periodically images on the screen appear to Internet be distorted To prevent unauthorized access, note the following. When the camera is installed in a location where • Leave user authentication turned on. it is subject to small vibrations (for example, when •...
  • Page 7 Cleaning the lens Router Use a lens cleaning paper (used to clean camera When connecting this product to the Internet, lenses or lenses of spectacles). When using use a broadband router with the port forwarding solvent, use an alcohols solvent and do not use a function (NAT, IP masquerade).

  • Page 8: Parts And Functions

    Parts and functions ■ Indicator and button ③ACT indicator ②LINK indicator ①INITIAL SET button ① INITIAL SET button (Initializing) Follow the steps below to initialize the network camera. ⑴ Turn off the power of the camera. When using a PoE hub, disconnect the Ethernet cable from the camera. When using an external power supply, disconnect the power cord plug (accessory) from the power supply terminal (12V DC).
  • Page 9 ② LINK indicator • When the camera is able to communicate with the connected device Lights orange ③ ACT indicator • When data is being sent via the network camera Blinks green (accessing)

  • Page 10: Troubleshooting

    Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using a PoE device for power supply...

  • Page 11: Detail Specifications

    ■ With mounting seat and protective cover Approx. 197 g {0.43 lbs} Finish PC resin, Aluminum die cast i-PRO white *1 Refer to our technical information website <Control No.: C0106> for further information about Power source and Power consumption information.
  • Page 12 Camera • Image sensor: Approx. 1/2.8 type CMOS image sensor Effective pixels: Approx. 2.1 megapixels Scanning area: 5.57 mm (H)×3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)} Scanning system: Progressive Minimum illumination: Color: 0.21 lx {0.0196 footcandle} (30IRE, F2.0, Maximum shutter: Off (1/30 s), AGC: 11) 0.3 lx {0.0279 footcandle} (50IRE, F2.0, Maximum shutter: Off (1/30 s), AGC: 11) 0.019 lx {0.0018 footcandle}...
  • Page 13 *1 When the 320x180 resolution is used, the “90°” and “270°” settings are not available. *2 When [16:9 mode (30 fps mode)] or [16:9 mode (25 fps mode)] is used, the “90°” and “270°” settings are available.
  • Page 14 Lens • Zoom ratio: Optical zoom Extra optical zoom Max 3.0× (1.0× – 3.0× when resolution is 640×360) Focal length: 3.2 mm {1/8 inches} Maximum aperture ratio: 1:2.0 Focus range: 0.5 m {1/32 inches} – ∞ Aperture range: F2.0 Angular field of view: [16:9 mode] Horizontal: 81.1°...
  • Page 15 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution : [16:9 mode (30 fps mode/25 fps mode)] H.265/ H.264 * 1920×1080/ 1280×720/ 640×360/ 320×180 JPEG (MJPEG) [4:3 mode (30 fps mode/25 fps mode)] 1280x960/ 640x480/ 320x240 [4:3 mode (15 fps mode/12.5 fps mode)] 2048x1536 * / 1280x960/ 640x480/ 320x240 Image compression method :...
  • Page 16 <Control No.: C0132>. *5 When using MJPEG/JPEG (Refresh interval) only. *6 Use a microSD memory card dedicated to i-PRO cameras. *7 For possible number of images and duration (an indication) that can be saved on the microSD memory card, refer to our technical information website below.
  • Page 17 *8 Use the microSD memory card with SD Speed Class 6 or higher. Use the microSD memory card that complies with UHS-1(Ultra High Speed-1) in the case of SD Speed Class 10. *9 Refer to our technical information website <Control No.:C0117> for the replacement cycle (target) of a microSD memory card.
  • Page 18 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 av0032-0 PGQP3464ZA...
