MOD-5532/5533
STEP 3:
Place Center Rail (7) and 4 pieces of Support Leg (8) under assembled Double Slat (4) and Single Slat (5) as shown.
Insert 4 pieces of Long Bolt (C) into the 4 holes right on Center Rail (7) to connect it with Support Legs (8) as shown.
Insert 4 pieces of Medium Bolt (B) into 4 other holes left on Center Rail (7) to connect it with Support Legs (8) as shown.
Secure the above 8 pieces of Bolts (B&C) with Nuts (D) from the bottom of Support Legs (8) at same time.
Use Allen Wrench (G) and Open Wrench (H) to fixation all Bolts (B&C) and Nuts (D) until secure.
3
7
4
8
Bx4 Cx4
STEP 4:
Insert Bolts (A) into the bottom holes on the assembled Headboard (1&6) & Footboard (2) by hand.
Leaving 0.3~0.4inch space of the thread of Bolts (A) as shown for inserting the notch of assembled Side Rails (3&4&5).
Insert the notch of assembled Side Rails (3&4&5) into the space left on the Bolts (A).
Screw Bolts (A) into the top holes on the assembled Headboard (1&6) & Footboard (2) as shown.
Fixation
Bolts (A) with Allen Wrench (G) after all assembled.
STEP 5:
Tighten all Bolts with Allen Wrench (C),after all assemlded
AX8
Customer Service 908-368-1025︱www.modwayfurniture.com
FULL/QUEEN BED
4
5
4
5
3
Dx8 Gx1
6
3
2
Top Hole
Bottom Hole
A
6
Assembly is completed. Your bed is ready to be enjoyed now!
Gx1
4
5
Hx1
1
6
3
0.3~0.4inch
3
Notch
6
A
G
C
4
B
7
H
D
D
8
Hardware & Tool required
A
G
3
6
Hardware & Tool required
