Parts List - Linear Technology DC1891A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CC2
2 4 C3, C4, CSS, C5
3 1 CC1
4 1 C1
5 1 C2
6 1 CIN4
7 1 CU1
8 7 CS1 TO CS4, CIN1 TO CIN3
9 4 COUT1 TO COUT4
10 2 COUT5, COUT6
11 1 CF
12 2 D3, D5
13 1 D4
14 2 D1, D2
15 2 Q2, Q4
16 1 Q5
17 2 Q6, Q8
18 1 Q7
19 1 RC1
20 1 ROSC
21 2 R4, R10
22 2 RF, R17
23 1 R9
24 1 R1
25 1 R3
26 1 R11
27 2 R6, R8
28 1 R12
29 1 R13
30 1 R14
31 2 R15, R16
32 1 R19
33 1 R20
34 2 T1,T2
35 1 U1
PART DESCRIPTION
CAP, NPO 100pF, 25V, 5%, 0603
CAP, X7R 0.01µF 25V 10% 0603
CAP, X5R 0.015µF 25V 10% 0603
CAP, NPO 1000pF 25V 10% 0603
CAP, X5R, 2.2µF, 25V, 10%, 0805
CAP, 33µF, 63V
CAP, X7R 4.7µF 50V 10% 1206
CAP, X7S 4.7µF 100V 20% 1812
CAP, X7S 47µF 16V 20% 1812
CAP, 220µF 16V APXE
CAP, X7R 0.01µF 16V 10% 0603
ZENER DIODE, SOD-323
DIODE, SOD-523
SCHOTTKY RECTIFIER, TO-277A
POWER MOSFET, PG-TDSON-8
PNP TRANSISTOR, SOT-23
NPN TRANSISTOR, SOT-323
NPN TRANSISTOR, SC-75
RES, CHIP 13.7k, 1% 0603
RES, CHIP 43.2k, 1% 0603
RES, CHIP 10Ω 5% 0603
RES, CHIP 0Ω, Jumper 0603
RES, CHIP 110k, 1% 0805
RES, CHIP 12.4k, 1% 0603
RES, CHIP 845k, 1% 0603
RES, CHIP 249k, 1% 0603
RES, 0.005Ω, 1/2W, 1%, 2010
RES, CHIP 33k, 1% 0603
RES, CHIP 220k, 1% 0603
RES, CHIP 56k, 1% 0603
RES, CHIP 10k, 1% 0603
RES, CHIP 100k, 1% 0603
RES, CHIP 180k, 1% 0603
COUPLED INDUCTOR, 6.8µH
PWM CONTROLLER LTC3862EFE-2
DEMO MANUAL DC1891A
MANUFACTURER/PART NUMBER
AVX 06033A101JAT2A
AVX 06033C103KAT2A
AVX 06033D153KAT2A
AVX 06033A102JAT2A
AVX 08053D225KAT2A
SUN ELECT, 63HVH33MS
MURATA GRM31CR71H475KA12L
TDK C4532X7S2A475M
TDK CKG45NX7S1C476M
UNITED CHEMI-CON APX160ARA221MHA0G
AVX 0603YC103KAT2A
NXP SEMI PDZ6.8B
NXP SEMI BAS516
VISHAY V8P10-M3/86A
INFINEON BSC060N10NS3G
NXP SEMI PBSS9110T
NXP SEMI PMST5550
NXP SEMI BC847T
VISHAY CRCW060313K7FKEA
VISHAY CRCW060343K2FKED
VISHAY CRCW060310R0JNEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW0805110KFKEA
VISHAY CRCW060312K4FKEA
VISHAY CRCW0603845KFKEA
VISHAY CRCW0603249KFKEA
VISHAY WSL20105L000FEA
VISHAY CRCW060333K0FKEA
VISHAY CRCW0603220KFKEA
VISHAY CRCW060356K0FKEA
VISHAY CRCW060310K0FKEA
NIC NRC06F1003TRF
VISHAY CRCW0603180KFKEA
WÜRTH 7448709068
LINEAR TECHNOLOGY LTC3862EFE-2
dc1891af
5
