RFID locks operate with an RFID Card. In shared use functionality, the user chooses any available locker and presents any RFID
Card to lock and unlock. Once unlocked, the locker is available for a different user. Management staff operates the lock with either the
Programming Key unique to the lock system or any registered Manager Bypass Key.
Lock Parts
Front Unit
Reader
Key Slot
Pull Handle
Rear Unit
Cover Plate
Advanced Security
Keys
Programming Key
■
Registers Manager Bypass Keys
■
Provides lock access in case of forgotten/lost user
credential (card or key)
■
Allows management audit/inspection
1 Programming Key required per lock system
■
Key Insertion
Standard Body
Digilock logo must face up on standard and vertical body locks.
Product Guide
RFID Locks Advanced Security
LED Usage
Indicator
Key Button
Standard Body
DAR1-ATS1
Mounting Holes
Cover Plate Screws
1/2" (12mm) Deadbolt
Manager Bypass Key
■
Provides lock access in case of forgotten/lost
user credential (card or key)
■
Allows management audit/inspection
■
Provides external power in case of battery failure
Up to 25 Manager Bypass Keys may be registered
■
per lock
Vertical Body
Shared Use
DAR1-ATS1 & DAR1-ATV1
Key Slot
Pull Handle
Vertical Body
DAR1-ATV1
LED Usage
Indicator
Reader
Key Button
RFID Card
User Key
Operates the lock instead of
■
RFID Card
■
ADA compliant*
*US Access Board requires 5% of all
locks to be ADA compliant.
Phone: 707 766 6000
www.digilock.com | sales@digilock.com
