Keypad cam locks operate by entry of a 4-digit code. In assigned use functionality, a 4-digit User Code is assigned to operate the lock.
To unlock, the user enters the assigned User Code then rotates the knob/lever to the unlocked position. To lock, the user closes the
door then rotates the knob/lever to the locked position. Management staff operates the lock with either the Programming Key unique to
the lock system or any registered Manager Key.
Lock Parts
Front Unit
Key Slot
C Button
Unlocked Position
Locked Position
DCK1-APV1 with Knob
Rear Unit
Rear Cover
Keys
Programming Key
■
Registers Manager Keys
■
Provides lock access in case of forgotten/lost user
credential (code or key)
■
Allows management audit/inspection
■
Provides external power in case of battery failure
■
1 Programming Key required per lock system
Key Insertion
Vertical Body
Digilock logo must face up on vertical body locks.
Product Guide
Keypad Cam Locks Advanced Security
LED Usage Indicator
Alpha Numeric Keypad
Key Symbol Button
Knob
Vertical Body
Rear Cover Screw
Cam
Manager Key
Assigns User Code and User Key
■
Provides lock access in case of forgotten/lost
■
user credential (code or key)
■
Allows management audit/inspection
■
Provides external power in case of battery failure
■
Up to 25 Manager Keys may be registered
per lock
Assigned Use
DCK1-APV1
Key Slot
C Button
Unlocked Position
Locked Position
Vertical Body
DCK1-APV1 with Lever
LED Usage Indicator
Alpha Numeric Keypad
Key Symbol Button
Lever
User Key
■
Operates the lock instead of
User Code
■
ADA compliant*
*US Access Board requires 5% of all
locks to be ADA compliant.
Phone: 707 766 6000
www.digilock.com | sales@digilock.com
