RFID cam locks operate with an RFID Card or RFID Access Credential. In shared use functionality, the user chooses any available
locker, presents any RFID Card or Credential, then rotates the knob/lever to the locked position. To unlock, the user presents the same
RFID Card or Credential, then rotates the knob/lever to the unlocked position. Once unlocked, the locker is available for a different user.
Management staff operates the lock with either the Programming Key unique to the lock system or any registered Manager Key.
Lock Parts
Front Unit
Key Slot
Unlocked Position
Locked Position
DCR1-ATV1 with Knob
Rear Unit
Rear Cover
Keys
Programming Key
■
Registers Manager Keys
■
Provides lock access in case of forgotten/lost user
credential
■
Allows management audit/inspection
■
1 Programming Key required per lock system
Key Insertion
Vertical Body
Digilock logo must face up on vertical body locks.
Product Guide
RFID Cam Locks Advanced Security
LED Usage Indicator
Reader
Key Symbol Button
Knob
Vertical Body
Rear Cover Screw
Cam
Manager Key
■
Provides lock access in case of forgotten/lost
user credential
■
Allows management audit/inspection
■
Provides external power in case of battery failure
■
Up to 25 Manager Keys may be registered
per lock
Shared Use
DCR1-ATV1
Key Slot
Unlocked Position
Locked Position
Vertical Body
DCR1-ATV1 with Lever
LED Usage Indicator
Reader
Key Symbol Button
Lever
RFID Card
User Key
■
Operates the lock instead of
RFID User Credential
■
ADA compliant*
*US Access Board requires 5% of all
locks to be ADA compliant.
Phone: 707 766 6000
www.digilock.com | sales@digilock.com
