S T E P 4
Remove the floor panel.
S T E P 5
Remove the tool kit, the two storage pockets, the spare tire,
and the padding from the tire well.
S T E P 6
Remove the two hex nuts that hold the rear of the plastic
tub in place.
S T E P 7
Remove the seat extension panel by carefully pulling up on
the panel to release the clips.
SB-J-GCHWK2/10W3v3 INSTR_SKU# 011321
S T E P 8
From behind the back seat, remove the two Phillips head
screws that hold the front of the plastic tub in place, then
remove the tub.
S T E P 9
Remove the right rear door sill panel by carefully pulling up
on the panel to release the clips.
S T E P 1 0
Pull the weather-stripping away from the side panel as
shown, then unclip the side panel.
S T E P 1 1
Disconnect the power outlet from the side panel, and
remove the panel from the vehicle.
Continued on Next Page
