I N S T A L L A T I O N G U I D E
for the
SB-GM-COCREW2G/10TW3
SKU# 94635
2015-Up Chevrolet Colorado & GMC Canyon Crew Cab
Enclosure Type: Sealed
Driver Type: 10TW3-D4
Nominal Impedance: 2 ohms
Continuous Power Handling: 400 watts (RMS method)
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox
be properly mounted to the vehicle
®
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
SB-GM-COCREW2G/10TW3 INSTR_SKU# 011474
INSTALLATION
DIFFICULTY:
1
OUT
ESTIMATED TIME:
1 HOUR
Continued on Next Page
5
OF
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JL Audio 94635
Summary of Contents for JL Audio 94635
- Page 1 1 HOUR Thank you for choosing a JL Audio Stealthbox® for your automotive sound system. With proper installation, your new vehicle-specific enclosed subwoofer system I N S T A L L A T I O N G U I D E will deliver years of listening pleasure.
- Page 2 I N C L U D E D H A R D WA R E BOM ID Description 151137 1/4 - 20 x 1” Hex Bolt 1/4” Split Lock Washer 151098 150068 1/4” Flat Washer 153859 Short Bracket 153860 Long Bracket Page 2 • JL Audio, Inc., 2017 Continued on Next Page...
- Page 3 Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your Stealthbox® amplifier. Other kits are available should you be using more than one amplifier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for both channels of the amplifier.
- Page 4 Short Bracket, and partially thread it into the front factory hole. Align the Short Bracket horizontally, with the slotted end facing inward, as shown. Mark the location of the Short Bracket on the carpet. Page 4 • JL Audio, Inc., 2017 Continued on Next Page...
- Page 5 Note the location of the threaded studs in the Replace the jack tools, if desired, and fold the back of the vehicle. Push the carpet down, rear seats back down. leaving the threaded studs exposed. Page 5 • JL Audio, Inc., 2017 Continued on Next Page...
- Page 6 . j l a u d i o . c o m All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox®” and the Stealthbox logo, and “How we play®” are registered trademarks of JL Audio, Inc.
