2009 & up ford f150 supercrew

Advertisement

Quick Links

StealthMod
I N S T A L L A T I O N G U I D E
for the
SMS-F150-SPRCRW/PREM
SMS-F150-SPRCRW/BAS
SKU# 94550 and 94551
2009 & Up Ford F150 SuperCrew
Thank you for choosing a JL Audio StealthMod® System for your automotive sound system.
With proper installation, your new vehicle-specific audio system
will deliver years of listening pleasure.
We strongly recommend that you have your new StealthMod® System installed by your authorized
JL Audio dealer. The installation professionals employed by your dealer have the necessary tools
and experience to disassemble and reassemble your vehicle properly. If you prefer to perform your
own installation, please read this installation guide completely before beginning the process.
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
S T E A L T H B O X ® S P E C I F I C A T I O N S
Enclosure Type: Sealed
Driver Type: 13TW5v2-2
Nominal Impedance: 2 ohms
Continuous Power Handling: 600 watts (RMS method)
I N C L U D E D E Q U I P M E N T
(1) C3-570 Speakers
(1) XD700/5 Amplifier
(1) HD-RLC
I N C L U D E D H A R D W A R E
(2) Crossover Brackets
(1) F150 Amplifier Bracket
(1) 60 Amp Ground Wire
(2) 4 Gauge Ring Terminals
(1) Remote Turn-on Wire
(1) Mini Fuse Add-A-Circuit
(1) 3 Amp Mini Fuse
(1) 10 Amp Mini Fuse
(1) 16 Gauge Speaker Cable
(1) 12 Gauge Speaker Cable
(4) 10 - 24 x 3/8" Machine Screw
(4) #8 x 1" Phillips Pan Head Screw
Premium Model Only
(1) CL-LSA Load Sensing Adaptor
(1) CL-LSA Speaker Input Harness
(1) CL-LSA RCA Output Harness
(2) XD-CLRAIC2-9 Audio Interconnect
®
be properly mounted to the vehicle according to these
(2) Foam Tape
(1) 60 Amp Power Wire
(1) XD-MFB-MAXI Master Fuse Block
(1) 60 Amp MAXI Fuse
(1) XB-MGLU Master Ground Lug
(3) 1/4 - 20 x 1" Bolt
(3) 1/4" Lock Washer
(3) 1/4" Flat Washer
(3) 1/4 - 20 U-Nut
(8) Speed Clip
(4) #8 x 3/4" Screw
(4) 10 - 24 Keps Nut
Basic Model Only
(2) Speaker Wire to RCA Adaptor
(2) XD-CLRAICY1F2M Y-adaptor
(2) XD-CLRAIC2-12 Audio Interconnect
SMS-F150-SPRCRW INSTR_SKU# 011341
INSTALLATION
D I F F I C U L T Y :
4
OUT
5
OF
ESTIMATED TIME:
5-6 HOURS
Continued on Next Page

Advertisement

loading
Need help?

Need help?

Do you have a question about the StealthMod SMS-F150-SPRCRW/PREM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JL Audio StealthMod SMS-F150-SPRCRW/PREM

  • Page 1 (1) XD-MFB-MAXI Master Fuse Block (2) 4 Gauge Ring Terminals (1) 60 Amp MAXI Fuse Thank you for choosing a JL Audio StealthMod® System for your automotive sound system. (1) Remote Turn-on Wire (1) XB-MGLU Master Ground Lug With proper installation, your new vehicle-specific audio system (1) Mini Fuse Add-A-Circuit (3) 1/4 - 20 x 1”...
  • Page 2 The diagram below shows the recommended crossover and input sensitivity settings for the XD700/5 for the Premium System. For a detailed description of the amplifier settings, consult the owner’s manual for the amplifier. Page 2 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 3 The diagram below shows the recommended crossover and input sensitivity settings for the XD700/5 for the Basic System. For a detailed description of the amplifier settings, consult the owner’s manual for the amplifier. Page 3 • JL Audio, Inc., 2013...
  • Page 4 S T E P 4 S T E P 8 Unplug and remove the enclosure. Remove the two screws at the bottom of the door panel. Page 4 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 5 S T E P 1 6 Using a flat blade screwdriver, carefully pry off the plastic ring Locate the two holes in the door as indicated. around the factory speaker as shown. Page 5 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 6: Premium System

    Basic Premium Left Front (+) = white white/brown Left Front (-) = white/brown white Right Front (+) = white/violet white/orange Left Front (-) = white/orange white/violet Page 6 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 7 Always wear eye protection when drilling! systems or anything else that might cause a reduction in your weekly pay. Page 7 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 8 Disconnect the negative battery post connection. Open the console lid and remove the three screws holding the lid to the console. Remove the lid. Unclip and remove the trim panel below the power outlet. Page 8 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 9 Right Front (+) = white/orange Right Front (-) = white/violet Left Rear (+) = brown/yellow Left Rear (-) = white/green Right Rear (+) = brown/blue Right Rear (-) = brown/white Page 9 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 10 S T E P 5 6 Remove the two screws under the tray. Open the glove compartment and squeeze the sides in order to drop it down as shown. Page 10 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 11 16 AWG Speaker Cable to the wire side. Connect the Audio Interconnects to the Speaker Wire to RCA Adaptors with the supplied barrel connectors. Page 11 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 12 Inputs 1-2 and 5-6. Connect the rear Audio Interconnects to Inputs 3-4. Connect the 16 Gauge Speaker Cables for the front speakers to the amplifier Outputs 1-2, and the rear to Outputs 3-4. Page 12 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 13 Attach two Enclosure Brackets to the threaded inserts on the Repeat for the opposite side. Stealthbox® using a pair of 1/4 - 20 x 1-1/2” Hex Drive Bolts as shown. Page 13 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 14 Using a 1/8” drill bit, drill floor. through the hole in the Trim Panel and into the Stealthbox® as shown. Page 14 • JL Audio, Inc., 2013 Continued on Next Page...
  • Page 15 . j l a u d i o . c o m All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered trademarks of JL Audio, Inc.,. “Ahead of the Curve” and its respective logo is a trademark of JL Audio, Inc.,.
