XR650-CXi
6.50-inch (160 mm) Coaxial Speaker System
o w n e r ' s m a n u a l
Thank you for choosing JL Audio Evolution XR Coaxials for your
automotive sound system. With proper installation, your new
speakers will deliver years of listening pleasure.
We strongly recommend that you have your new Evolution speakers
installed by your authorized JL Audio dealer. The installation
professionals employed by your dealer have the necessary tools and
experience to disassemble your interior panels, install your new
speakers and reassemble your vehicle properly. Also, keep in mind
that your warranty coverage extends to 1 year if your system is
installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this instruction
manual completely before beginning the process.
Advertisement
Related Manuals for JL Audio XR650-CXi
Summary of Contents for JL Audio XR650-CXi
- Page 1 6.50-inch (160 mm) Coaxial Speaker System o w n e r ’ s m a n u a l Thank you for choosing JL Audio Evolution XR Coaxials for your automotive sound system. With proper installation, your new speakers will deliver years of listening pleasure.
-
Page 2: Getting Started
Frequency Response: 48 Hz - 25 KHz (± 3 dB) Efficiency @ 1W/1m: 89.5 dB Nominal Impedance: 4 ohms Included Components and Parts: • Two XR650-CXi 6.50-inch (160 mm) Coaxial Speakers • Two XR650-CXpxo 2-Way Crossover Networks • Two Metal Woofer Grilles and Grille Trays •... - Page 3 HIGH MID NORMAL -1.5dB LOW MID -3.0dB JL AUDIO XR650-CXi ADJUSTABLE MIDRANGE PRESENCE: Your XR crossover networks also provide a unique midrange presence control, located under the clear cover (see Diagram C). The midrange presence is selectable via a set of pins and allows for three settings:“High-Mid”,“Normal”...
- Page 4 Make sure that the wires will clear door hinges and other structures in the door. If you are unsure about any part of this process, please contact your JL AUDIO dealer for installation help. Your new speakers have been designed to install, without modifications, into most vehicles that accept a 6.50-inch (160 mm) speaker.
- Page 5 Make sure that the wires will clear door hinges and other structures in the door. If you are unsure about any part of this process, please contact your JL AUDIO dealer for installation help. Double check the clearance for both speakers before proceeding.
- Page 6 CROSSOVER NETWORK INSTALLATION: The crossover networks supplied with your XR650-CXi System should be installed in a dry location of your vehicle. DO NOT INSTALL CROSSOVERS INSIDE OF A DOOR! Doors often get wet on the inside, which can damage your crossover networks and could potentially damage your entire sound system.
- Page 7 WARNING! The tweeter will rotate 45 degrees to either side of the center position. Do not force the tweeter beyond this limit of rotation or you may damage its wiring. JL AUDIO XR650-CXi...
- Page 8 (90) days from the original date of purchase. The warranty term is extended to one (1) year if installation is performed or approved by an authorized JL AUDIO dealer (proof of installation or approval required on purchase receipt).
