Labeling
Displaying Labels
with Traces
3 116
Labels of displayed traces may be displayed on the screen with the traces.
When Displayed Traces is selected, Display and Position selectors appear
to the right of the trace selectors in the Labeling pop up menu. Turning on
Display will cause the labels to appear with the traces. Labels will appear in
the selectors for all traces whether Display is turned on or off.
Labels that are displayed on the screen move with the traces. You can
position each label relative to its trace. Select Position to assign the knobs
to set the vertical (top knob) and horizontal (bottom knob) position of the
label. The label position is relative to a specific point on the trace. By chang
ing the horizontal position of the label, you are changing the point the label
will follow. By changing the vertical label position, you can specify the verti
cal offset of the label from the point. If the trace record point is out of the
range of the graticule, the label will remain at the top or bottom of the grati
cule.
You can select a trace by touching its displayed label.
