OSP Home Furnishings HILLSBORO HSB30 Manual

File cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
November, 2018
HSB30
HILLSBORO FILE CABINET
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.

Advertisement

loading

Related Manuals for OSP Home Furnishings HILLSBORO HSB30

Summary of Contents for OSP Home Furnishings HILLSBORO HSB30

  • Page 1 November, 2018 HSB30 HILLSBORO FILE CABINET Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.

  • Page 2: Limited Warranty

    LIMITED WARRANTY OSP Home Furnishings™ warrants to the original purchaser that this product will be free from defects in material and workmanship as described below. OSP Home Furnishings™ will repair or replace, at its option, without charge to the original purchaser only, defective products or parts for one (1) year from the date of purchase.
  • Page 3 PARTS (A) Drawer front Panel (2 PCS) (B) Left Drawer Side Panel (2 PCS) (C) Right Drawer Side Panel (2 PCS) (D) Rear Drawer Panel (2 PCS) (E) Bottom Drawer Panel (2 PCS) (F) Top (1 PC) (G) Front Frame (1 PC) (H) Left Frame (1 PC) (I) Right Frame (1 PC) (J) Rear Panel (1 PC)

  • Page 4: Hardware List

    PARTS (K) Stretcher (2 PCS) HARDWARE LIST DRAWING DESCRIPTION SIZE QUANTITY Bolt 1/4” x 35mm 12 PCS Short Screw 4 x 20mm 12 PCS 4 x 35mm Long Screw 24 PCS Lock Washer 1/4” 8 PCS Flat Washer 5/16” x 19 8 PCS Wooden Dowel 5/16”...

  • Page 5: Drawer Installation

    DRAWER INSTALLATION If you need to remove the drawer with ball bearing slides from the unit, follow the steps below to prevent any damage to the slides or the drawer. If you need to remove the drawer, please pull the drawer all the way out, then push the plastic release lever of the ball bearing slide up on one side and down on the other side, and then pull the drawer completely out.
  • Page 6 STEP 1 DO NOT FULLY TIGHTEN SCREWS (3). STEP 2...
  • Page 7 STEP 3 DO NOT FULLY TIGHTEN SCREWS (3). STEP 4 FULLY TIGHTEN ALL SCREWS (3).
  • Page 8 STEP 5 FULLY TIGHTEN ALL SCREWS (7). REPEAT STEPS 1-5 FOR SECOND DRAWER. STEP 6...
  • Page 9 STEP 7 (4) (8) (5) (1) (1) (8) DO NOT FULLY TIGHTEN BOLTS (1). STEP 8 (1) (8) DO NOT FULLY TIGHTEN BOLTS (1).
  • Page 10 STEP 9 FULLY TIGHTEN ALL BOLTS (1). STEP 10 FULLY TIGHTEN ALL SCREWS (2).
  • Page 11 STEP 11 SLIDE DRAWER INTO FILE CABINET.
