BP-4210
NASHVILLE KITCHEN ISLAND
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.
Advertisement
Related Manuals for OSP Home Furnishings NASHVILLE BP-4210
Summary of Contents for OSP Home Furnishings NASHVILLE BP-4210
- Page 1 July, 2019 BP-4210 NASHVILLE KITCHEN ISLAND Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.
-
Page 2: Limited Warranty
LIMITED WARRANTY OSP Home Furnishings™ warrants to the original purchaser that this product will be free from defects in material and workmanship as described below. OSP Home Furnishings™ will repair or replace, at its option, without charge to the original purchaser only, defective products or parts for one (1) year from the date of purchase. - Page 3 PARTS (A) Top (1 PC) (B) Body (1 PC) (C) Left Side Frame (1 PC) (D) Right Side Frame (1 PC) (E) Bottom Frame (1 PC) (F) Left Door (1 PC) (G) Right Door (1 PC) (H) Back Frame (1 PC) (I) Middle Shelf (1 PC) (J) Adjustable Shelf (2 PCS)
-
Page 4: Hardware List
HARDWARE LIST DRAWING DESCRIPTION SIZE QUANTITY Screw 3.5 x 15mm 8 PCS Screw M4 x 25mm 2 PCS Screw M4 x 35mm 2 PCS Bolt M6 x 35mm 35 PCS Bolt M4 x 50mm 4 PCS Bolt M6 x 70mm 4 PCS Lock Washer 39 PCS... - Page 5 STEP 1 (13) FULLY TIGHTEN ALL BOLTS (4). STEP 2 (11) (C & D) FULLY TIGHTEN ALL BOLTS (5).
- Page 6 STEP 3 (13) (13) (8) (4) (13) (13) FULLY TIGHTEN ALL BOLTS.
- Page 7 STEP 4 (13) FULLY TIGHTEN ALL BOLTS (4). STEP 5 (13) (12) FULLY TIGHTEN ALL BOLTS (6). FULLY TIGHTEN ALL SCREWS (1) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
- Page 8 STEP 6 (10) (10) FULLY TIGHTEN ALL SCREWS USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
- Page 9 July, 2019 BP-4210 NASHVILLE STOOL Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.
- Page 10 LIMITED WARRANTY OSP Home Furnishings™ warrants to the original purchaser that this product will be free from defects in material and workmanship as described below. OSP Home Furnishings™ will repair or replace, at its option, without charge to the original purchaser only, defective products or parts for one (1) year from the date of purchase.
- Page 11 PARTS (A) Seat Frame (1 PC) (B) Leg (4 PCS) (C) Long Stretcher (2 PCS) (D) Short Stretcher (2 PCS) HARDWARE LIST DRAWING DESCRIPTION SIZE QUANTITY Screw M4 x 45mm 8 PCS Bolt M6 x 45mm 8 PCS Lock Washer 8 PCS Flat Washer 8 PCS...
- Page 12 STEP 1 (5) (2) (3) (4) FULLY TIGHTEN ALL BOLTS (2). FULLY TIGHTEN ALL SCREWS (1) USING PHILLIPS SCREWDRIVER (NOT PROVIDED).
