TS2000: Tripod Turnstile
TS2011: Tripod Turnstile with Controller and RFID Reader
TS2022: Tripod Turnstile with Controller and Fingerprint Reader with RFID function.
Please read this document carefully before installation and using the device.

1. Technical Specifications

Input Voltage
Rated Power
Operating Environment Indoor and Outdoor (shelter)
Operating Temperature
Operating Humidity
Flow Rate
Input Control Signal
2. Arm Installation and Equipment Testing
2.1 Arm installation method
Installation procedure
1. Using the glue and applying in the hole of the arms as
well as the one screw, as shown in Figure 2-1. (This is to
prevent screws from getting loose due to vibration after
being used for a long time.)
AC 100~120V /200~240V,
50Hz /60Hz
60 W
-28ºC ~ 60ºC
5% ~ 85%
25~30 passages / minute
Dry contact
Figure 1
Max. Tolerance of Arms
Ingress Protection Degree
Arm Length (mm)
Net Weight
Gross Weight
Dimension(mm) Figure 1 L = 1110, W = 260, H = 985
Package Size (mm)
This hole shall be applied
with glue evenly.
1
Center: 80 kg
End: 40 kg
IP54
520
46kg
54kg
L = 1200, W = 380, H = 1080
Figure 2-1
