  • Page 1 Primary Tillage TrackMaster II Serial Number A66960100 & Higher Part No. J08000010...

  • Page 2: Pre-Delivery Checklist

    — Introduction TrackMaster II Foreword This symbol identifies important safety messages. When you see it, read the message that follows and be alert to the possibility of personal injury. Remember, safety instructions stated in this manual are for your protection. Read them carefully and follow them closely when working around or using this machine.

  • Page 3: Product Information

    • Serial number All products manufactured by Unverferth Mfg. Co., Inc. are warranted to be free from material and workmanship defects for one full year from time of consumer delivery. Your local dealer will gladly assist you with any warranty questions.

  • Page 4: Table Of Contents

    — Introduction TrackMaster II TABLE OF CONTENTS Foreword ............................... 2 Pre-Delivery Checklist ........................... 2 Product Information ............................3 SECTION I Safety General Hazard Information ........................1-2 Safety Decals .............................1-3 Following Safety Instructions ........................1-4 Before Servicing ............................1-4 Before Operating ............................1-4 During Operation ............................1-5 Pressurized Oil ............................1-5 Preparing for Emergencies ........................1-6 Wearing Protective Equipment ........................1-6...
  • Page 5 — Introduction TrackMaster II TABLE OF CONTENTS SECTION IV Maintenance Daily Service ..............................4-2 Beginning of Day ..........................4-2 End of Day ............................4-2 Annual Service ............................4-2 Beginning of Season ..........................4-2 End of Season ............................4-2 Lubrication ..............................4-3 Hub Assembly ............................4-3 Complete Torque Chart ..........................4-4 Hydraulic Fittings ............................4-5 SECTION V Parts...
  • Page 6 — Introduction TrackMaster II Notes...

  • Page 7: Section I

    — Safety TrackMaster II SECTION I Safety General Hazard Information ........................1-2 Safety Decals .............................1-3 Following Safety Instructions ........................1-4 Before Servicing ............................1-4 Before Operating ............................1-4 During Operation ............................1-5 Pressurized Oil ............................1-5 Preparing for Emergencies ........................1-6 Wearing Protective Equipment ........................1-6...

  • Page 8: General Hazard Information

    It is said that, “the best kind of a safety device is a careful operator.” We, at Unverferth Mfg. Co., Inc. ask that you be that kind of operator.

  • Page 9: Safety Decals

    — Safety TrackMaster II Safety Decals 9003126 97972 9003126 97961 99507 9003127 Guide Cone Stabilizer Hydraulic Lift Assembly Option 93551...

  • Page 10: Following Safety Instructions

    — Safety TrackMaster II Following Safety Instructions • Read and understand this operator’s manual before operating. • All machinery should be operated only by trained and authorized personnel. • To prevent machine damage, use only attachments and service parts approved by the manufacturer.

  • Page 11: During Operation

    — Safety TrackMaster II During Operation • Do not allow anyone to ride on the equipment. Never dismount from moving vehicle. Severe injury or death can occur from being run over by the equipment. • Regulate speed to field conditions. Maintain complete control at all times. •...

  • Page 12: Preparing For Emergencies

    — Safety TrackMaster II Preparing for Emergencies • Keep a first aid kit and properly rated fire extinguisher nearby. • Keep emergency numbers for fire, rescue, and poison control personnel near the phone. Wearing Protective Equipment • Wear clothing and personal protective equipment appropriate for the job.

  • Page 13: Set Up

    — Set Up TrackMaster II SECTION II Set Up Set Up ...............................2-2 Mounting Disc Assemblies on 3-Bar Frame .....................2-3 Guide Cone Stabilizer Assembly ........................2-4 Guide Cone Stabilizer Hydraulic Lift Assembly Option ................2-5 LevelPro Option Assembly .........................2-7 4-Bar Conversion Option Assembly ......................2-11 PackerPro Option Assembly ........................2-16...

  • Page 14: Set Up

    — Set Up TrackMaster II Set Up • READ AND UNDERSTAND SAFETY RULES BEFORE OPERATING OR SERVICING THIS MACHINE. REVIEW THE SAFETY SECTION IN THIS MANUAL IF NECESSARY. • TIPPING OR MOVEMENT OF THE MACHINE CAN CAUSE SERIOUS INJURY OR DEATH. BE SURE THE MACHINE IS SECURELY BLOCKED.

  • Page 15: Mounting Disc Assemblies On 3-Bar Frame

    JAAM4715 — Set Up TrackMaster II Mounting Disc Assemblies on 3-Bar Frame Using a safe lifting device and supports rated at a minimum of 1,500 lbs., place main frame on supports 36” to 42” high at each end. JAAM4714 Using a safe lifting device rated at a minimum of 100 lbs., mount the disc assemblies as shown in FIG.

  • Page 16: Guide Cone Stabilizer Assembly

    9800 — Set Up TrackMaster II Guide Cone Stabilizer Assembly 9388-108 Position the guide cone stabilizer mounting bracket weldment (JAM4772) around the 3rd link riser facing to the rear of the frame. Secure mounting bracket weldment (JAM4772) with 5/8”-11UNC x 7 1/2” U-bolts (JBP3331) and 5/8”-11UNC lock nuts (9801) (FIG.

  • Page 17: Guide Cone Stabilizer Hydraulic Lift Assembly Option

    — Set Up TrackMaster II Guide Cone Stabilizer Hydraulic Lift Assembly Option Remove the 5/8”-11UNC x 7 1/2” U-bolts (JBP3331), 5/8” lock washers (9404-029), and 5/8”-11UNC hex nuts (9394-014) from the guide cone stabilizer hydraulic lift assembly. Using a safe lifting device rated at a minimum of 300 lbs., raise the guide cone stabilizer hydraulic lift assembly to the center of the front frame as shown in FIG.
  • Page 18 — Set Up TrackMaster II Guide Cone Stabilizer Hydraulic Lift Assembly Option (continued) Purging Hydraulic System • RELIEVE HYDRAULIC SYSTEM OF ALL PRESSURE BEFORE ADJUSTING OR SERVICING. SEE TRACTOR OPERATOR'S MANUAL FOR PROPER PROCEDURES. HIGH-PRESSURE FLUIDS CAN PENETRATE THE SKIN AND CAUSE SERIOUS INJURY •...

  • Page 19: Levelpro Option Assembly

    — Set Up TrackMaster II LevelPro Option Assembly Using a safe lifting device rated at a minimum of 50 lbs., position offset stagger bracket weldments (JAM2394) to the rear tube of the TrackMaster as shown in FIG. 2-6. FIG. 2-6 8"...
  • Page 20 — Set Up TrackMaster II LevelPro Option Assembly (continued) Center the mounting plates (JAM7637) on the bottom of the offset stagger bracket weldments (JAM2394). Secure with 3/4”-10UNC x 5 11/16” U-bolts (JBP3208), 3/4” lock washers (9404-033), and 3/4”-10UNC hex nuts (9394-016) (FIG. 2-8). Torque hardware according to “Torque Chart”...
  • Page 21 — Set Up TrackMaster II LevelPro Option Assembly (continued) Attach the reflectors, RED (9003126), to the torsion spring weldments (JAM4921 & Torsion Spring JAM4922). (FIG. 2-10) Weldment Left-Hand (JAM4921) Loosely attach the torsion spring weldment left-hand (JAM4921) to the top of the mounting plate (JAM7637) on the left- hand side with 5/8”-11UNC x 4”...
  • Page 22 — Set Up TrackMaster II LevelPro Option Assembly (continued) Using a safe lifting device rated at a minimum of 300 lbs., center the leveler coil assembly with leveler mounting plates and flange bearings in between the torsion spring weldments (JAM4921 & JAM4922). (FIG. 2-11) NOTE: The leveler coil assembly spiral must face towards the front.

  • Page 23: 4-Bar Conversion Option Assembly

    — Set Up TrackMaster II 4-Bar Conversion Option Assembly Attach the stub extension bracket weldments (JAM4935BB) to the 3-bar frame sides with 3/4”-10UNC x 2 1/2” capscrews (9390-147) and 3/4”-10UNC elastic lock nuts (9398-021). (FIG. 2-12) 3/4”-10UNC Elastic 9398-021 Lock Nuts (9398-021) Stub Extension Bracket Weldments Stub Extension...
  • Page 24 — Set Up TrackMaster II 4-Bar Conversion Option Assembly (continued) Using a safe lifting device rated at a 100 lbs., loosen the 3/4”-10UNC x 5 11/16” U-bolts (JBP3208) and 3/4”-10UNC lock nuts (9802). Reposition left-hand and right-hand disc assemblies in rows 1 and 2 as shown in FIG. 2-13. FIG.
  • Page 25 — Set Up TrackMaster II 4-Bar Conversion Option Assembly (continued) Using a safe lifting device rated at a minimum of 50 lbs., relocate the 20” extension bracket weldments (JAM3400BB) to the outer-most position by loosening the 3/4”-10UNC x 7 3/4” U-bolts (JBP3047) and 3/4”-10UNC elastic lock nuts (9398-021). (FIG. 2-15) Using a safe lifting device rated at a minimum of 400 lbs., position the bolt-on 4-bar weldment (JAM4927BB), disc assemblies (JAAM4714 &...
  • Page 26 — Set Up TrackMaster II 4-Bar Conversion Option Assembly (continued) Using a safe lifting device rated at a 100 lbs., loosen the 3/4”-10UNC x 5 11/16” U-bolts (JBP3208) and 3/4”-10UNC lock nuts (9802) (FIG. 2-16). Relocate the disc assemblies as shown in FIG. 2-17. 3/4”-10UNC x 5 11/16”...

  • Page 27: Packerpro Option Assembly

    — Set Up TrackMaster II PackerPro Option Assembly Center the basket mounting plate (JAM7637) on the third frame bar. Mounting bracket must be offset forward of the third bar. Loosely secure with two 3/4”-10UNC x 5 11/16” U-bolts (JBP3208) and 3/4”-10UNC lock nuts (9802) (FIG. 2-18). FIG.
  • Page 28 — Set Up TrackMaster II PackerPro Option Assembly (continued) Using a safe lifting device rated at a 100 lbs., position the disc assemblies on the second frame bar FIG. 2-20. Loosely secure using 3/4”-10UNC x 5 11/16” U-bolts (JBP3208) and 3/4”-10UNC lock nuts (9802). 3/4”-10UNC x 5 11/16”...
  • Page 29 — Set Up TrackMaster II PackerPro Option Assembly (continued) Verify location of basket mount assembly and disc assemblies with FIG. 2-21. 14 3/4" 14 3/4" 15 3/8” 15 3/8” 8" 9 1/2" 9 1/2" 8" 8.5” 9.5” 9.5” 8.5” 6" 20 1/2"...
  • Page 30 — Set Up TrackMaster II Notes 2-18...

  • Page 31: Operation

    — Operation TrackMaster II SECTION III Operation Preparing Tractor ............................3-2 Preparing TrackMaster II ..........................3-3 Hardware .............................3-3 Pivot Pins ............................3-3 Guide Cone Stabilizer Hydraulic Lift Option Hydraulics ..............3-3 Bearings & Disc Blades ........................3-3 Lubrication ............................3-3 Attaching TrackMaster II to Tractor ......................3-4 Guide Cone Stabilizer Hydraulic Lift Option Hydraulic Hookup ............3-4 Transporting ...............................3-4 Unhitching From Tractor ..........................3-5...

  • Page 32: Preparing Tractor

    — Operation TrackMaster II Preparing Tractor Before operating implement refer to tractor operator’s manual for information concerning safe methods of operation, and tire inflation. Check tractor brakes and transport lights. Make sure they are in proper working order. Check tractor hydraulic oil reservoir and add oil if needed. TRANSPORTING THE IMPLEMENT SIGNIFICANTLY CHANGES THE WEIGHT AND BAL- •...

  • Page 33: Preparing Trackmaster Ii

    — Operation TrackMaster II Preparing TrackMaster II Perform the service checks as outlined. Repair or replace any damaged or worn parts before operating. Hardware Check for loose bolts and nuts, and tighten as needed. Check again after the first half-day of operation.

  • Page 34: Attaching Trackmaster Ii To Tractor

    Compliance with all lighting and marking laws is the responsibility of the operator at the time of travel. See federal regulation 49 CFR 562; available at www.govinfo.gov for US federal law requirements. See your Unverferth dealer for additional brackets, reflectors, or lights to meet your requirements.

  • Page 35: Unhitching From Tractor

    — Operation TrackMaster II Unhitching From Tractor • FALLING OR LOWERING EQUIPMENT CAN CAUSE SERIOUS INJURY OR DEATH. KEEP EVERYONE AWAY FROM EQUIPMENT WHEN RAISING OR LOWERING. • HIGH-PRESSURE FLUIDS CAN PENETRATE THE SKIN AND CAUSE SERIOUS INJURY OR DEATH. USE CARDBOARD OR WOOD TO DETECT LEAKS IN THE HYDRAULIC SYSTEM.
  • Page 36 — Operation TrackMaster II Notes...
  • Page 37 — Maintenance TrackMaster II SECTION IV Maintenance Daily Service ..............................4-2 Beginning of Day ..........................4-2 End of Day ............................4-2 Annual Service ............................4-2 Beginning of Season ..........................4-2 End of Season ............................4-2 Lubrication ..............................4-3 Hub Assembly ............................4-3 Complete Torque Chart ..........................4-4 Hydraulic Fittings ............................4-5...

  • Page 38: Maintenance

    — Maintenance TrackMaster II Daily Service Beginning of Day NOTE: Before initial use, ensure all lubrication points have been greased. Check all U-bolts and bolts for tightness. This is especially important during the first days of operation. See “Torque Chart” in this section. •...

  • Page 39: Lubrication

    — Maintenance TrackMaster II Lubrication • Do not use a high pressure grease gun to lubricate these bearings. Damage to bearing seals could occur. Lubricate with an SAE multi-purpose grease. All fittings must be free from dirt and paint to insure entry of lubrication inside bearing.

  • Page 40: Complete Torque Chart

    — Maintenance TrackMaster II Complete Torque Chart Capscrews - Grade 5 NOTE: • Grade 5 capscrews can be identified by three radial dashes on the head. • For wheel torque requirements, refer to Wheels and Tires. • Tighten U-bolts evenly and equally to have the same number of threads exposed on each end.

  • Page 41: Hydraulic Fittings

    — Maintenance TrackMaster II Hydraulic Fittings – Torque and Installation SAE FLARE CONNECTION (J. I. C.) Tighten nut with finger until it bottoms the seat. Using a wrench, rotate nut to tighten. Turn nut 1/3 turn to apply proper torque. SAE STRAIGHT THREAD O-RING SEAL Insure jam nut and washer are backed up to the back side of smooth portion of elbow adapter.
  • Page 42 — Maintenance TrackMaster II Notes...

  • Page 43: Parts

    — Parts TrackMaster II SECTION V Parts Frame Components & Disc Assembly (J80310051BB) ................5-2 Disc Assembly Components (J80310012) ....................5-4 Guide Cone Stabilizer Components (J80310014) ..................5-6 Guide Cone Stabilizer Hydraulic Lift Option (J80310035) ................5-8 LevelPro Option Components (J80310013) .....................5-10 PackerPro Option Components (J80310042) ...................5-12 4-Bar Conversion Option Components (J80310037BB) ................5-14...

  • Page 44: Frame Components & Disc Assembly (J80310051Bb)

    — Parts TrackMaster II Frame Components & Disc Assembly (J80310051BB) Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 45 — Parts TrackMaster II Frame Components & Disc Assembly (J80310051BB) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES TrackMaster II Assembly J80310051BB Includes Items 1-21 3-Bar Frame & Disc Assembly 9003126 Reflector RED, 2”x9”...

  • Page 46: Disc Assembly Components (J80310012)

    — Parts TrackMaster II Disc Assembly Components (J80310012) Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 47 — Parts TrackMaster II Disc Assembly Components (J80310012) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES J80310012 Disc Gang (3-Pair) Assembly with Hardware Includes Items 1 & 19 JAAM4714 Right-Hand Disc Assembly Includes Items 2-18...

  • Page 48: Guide Cone Stabilizer Components (J80310014)

    — Parts TrackMaster II Guide Cone Stabilizer Components (J80310014) Please visit www.unverferth.com/parts/ for the most current parts listing.
  • Page 49 — Parts TrackMaster II Guide Cone Stabilizer Components (J80310014) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES Includes Items J80310014 Guide Cone Stabilizer Assembly 1-12 9388-108 Carriage Bolt, 1/2”-13UNC x 2 1/2” G5 9392-180 Roll Pin, 3/8”...

  • Page 50: Guide Cone Stabilizer Hydraulic Lift Option (J80310035)

    — Parts TrackMaster II Guide Cone Stabilizer Hydraulic Lift Option (J80310035) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM...
  • Page 51 — Parts TrackMaster II Guide Cone Stabilizer Hydraulic Lift Option (J80310035) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES Includes Items J80310035 Guide Cone Stabilizer Hydraulic Lift Assembly 1-21 85632 Pin, 1” Dia. x 3 3/4”...

  • Page 52: Levelpro Option Components (J80310013)

    — Parts TrackMaster II LevelPro Option Components (J80310013) Please visit www.unverferth.com/parts/ for the most current parts listing. Cut End Towards Front 5-10...
  • Page 53 — Parts TrackMaster II LevelPro Option Components (J80310013) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES Includes Items J80310013 LevelPro Assembly 1-21 9390-080 Capscrew, 7/16”-14UNC x 1 1/2” G5 9390-101 Capscrew, 1/2”-13UNC x 1 1/2” G5 9394-010 Hex Nut, 1/2”-13UNC...

  • Page 54: Packerpro Option Components (J80310042)

    — Parts TrackMaster II PackerPro Option Components (J80310042) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM 5-12...
  • Page 55 — Parts TrackMaster II PackerPro Option Components (J80310042) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES J80310042 PackerPro Assembly Includes Items 1-22 9802 Lock Nut/Top, 3/4”-10UNC JBP3208 U-Bolt, 3/4”-10UNC x 5 11/16”, 6 13/16” C/C...

  • Page 56: 4-Bar Conversion Option Components (J80310037Bb)

    — Parts TrackMaster II 4-Bar Conversion Option Components (J80310037BB) Please visit www.unverferth.com/parts/ for the most current parts listing. 5-14...
  • Page 57 — Parts TrackMaster II 4-Bar Conversion Option Components (J80310037BB) Please visit www.unverferth.com/parts/ for the most current parts listing. ITEM PART NUMBER DESCRIPTION NOTES J80310037BB 4-Bar Conversion Option Includes Items 1-11 9003126 Decal, Reflector RED 2”x9” 9003127 Decal, Reflector AMBER 2”x9”...
  • Page 58 MANUALS\\J08000010//JULY 2020-1//November 2021-2...
