Unverferth Rolling Harrow II Operator's Manual/Parts Catalog

Models with 12 ft. & 15 ft. bases up to 37 ft., serial #0004026 through a38780100
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODELS WITH 12 FT. & 15 FT. BASES UP TO 37 FT.
Unverferth Mfg. Co., Inc.
P.O. Box 357 Kalida, OH 45853
Manual Part No. 84914 Replaces 84389
U n v e r f e r t h
Prescription Planting Products
OPERATOR'S MANUAL
&
PARTS CATALOG
ROLLING HARROW
(Serial #0004026 Through A38780100)
II
®
PH: 419-532-3121
FAX: 419-532-2468
www.unverferth.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rolling Harrow II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unverferth Rolling Harrow II

Summary of Contents for Unverferth Rolling Harrow II

  • Page 1 PARTS CATALOG ROLLING HARROW ® MODELS WITH 12 FT. & 15 FT. BASES UP TO 37 FT. (Serial #0004026 Through A38780100) Unverferth Mfg. Co., Inc. PH: 419-532-3121 FAX: 419-532-2468 P.O. Box 357 Kalida, OH 45853 www.unverferth.com Manual Part No. 84914 Replaces 84389...
  • Page 21 MAIN FRAME / HITCH FIG. 3-1 OM-00816 NOTE: For proper assembly of retaining rings, Using a hoist or safe lifting device, raise refer to page 16. unit and install wheels and tires onto axle. Position main frame into assembly area. NOTE: Torque all wheel bolts and nuts to 95 Ft.
  • Page 22 Place cylinders to machine with the NOTE: After wheel hoist cylinders are in place "ports" positioned to the top, except as and pinned into position, lower unit to ground. noted. NOTE: IF UNIT IS PURCHASED WITHOUT With a hoist, raise unit enough to re- WINGS, PROCEED TO STEP #34 (page 29).
  • Page 23 ASSEMBLY WING TRANSPORT WHEELS OPTIONAL ATTACHMENT -- AVAILABLE ON 16. Tighten all hardware. 7', 8', 9', 10', AND 11' WING SIZES ONLY. 17. Install tire and wheel assembly onto axle. NOTE: For proper assembly of retaining rings, refer to page 16. NOTE: Torque all wheel bolts and nuts to 95 Ft.
  • Page 24 ASSEMBLY 19. Place cylinders to machine with the "ports" positioned inward, toward the centerline of the machine. This requires the following change to both wing trans- port wheel cylinders (Fig. 3-6). Disassemble tie-rods from cylinder. Rotate rod end port 90 Reassemble and retighten tie-rods.
  • Page 25 ASSEMBLY WING FOLDING CYLINDERS BASE WING CYLINDER "A" DIM. TYPE OF (R.H. WING CYLINDER) 3000 PSI RATING SIZE SIZE SIZE (RETRACTED) WING FOLD SPACER LENGTH REQ'D 3-6' 3 x 16" 26 1/4" Flat ---- 4 x 16" 26 1/4" Stack 2 1/4"...
  • Page 26 ASSEMBLY Base C/C (Retracted) FIG. 3-10 OM-00205 IMPORTANT: On some units, the clevis must be adjusted to allow the wings to relax on the rest stands. Adjust as required. UNITS WITH STACK-FOLD WINGS FIG. 3-11 OM-00824 25. INSTALL SPACER TUBE ONTO ROD OF WING-FOLD CYLINDER (FIG.
  • Page 27 9874 Elbow damage to valve. 9876 Swivel Elbow ROLLING HARROW II serial #4025 and under 91608 Connector use valve 81827 in conjunction with wing style w/ Orifice shown in Fig. 3-13A. 81827...
  • Page 28 ASSEMBLY FIG. 3-13A FIG. 3-13A OM-01977 OM-01980 FIG. 3-13B FIG. 3-13B OM-01979 OM-01978 HYDRAULICS 34. INSTALL HYDRAULIC COMPONENT TO NOTE: Refer to the PARTS section for fitting THE MACHINE. type, hose size, and length required. IMPORTANT: DO NOT USE ANY TAPE OR Refer to the table (below) for determining the THREAD SEALANT AS ALL FITTINGS HAVE "HOSE ROUTING DIAGRAM"...
  • Page 29 ASSEMBLY HOSE ROUTING DIAGRAM 1 12 FT. & 15 FT. BASE MODELS To Tractor See View "A" Route Base - End Hose Under Frame Bar On Each Side Elbow Locking Cable Locking Cable Ties Elbow Refer to PARTS section (page 57) for hoses, fitting types, and position.
  • Page 30 ASSEMBLY HOSE ROUTING DIAGRAM 2 12 FT. BASE WITH FLAT-FOLD WINGS (3, 4, 5, & 6 FT. WINGS) Refer to PARTS section (page 58) for hoses, fitting types, and position. To Tractor See View "B" Route Hoses Under Hitch Tube See View "C"...
  • Page 31 ASSEMBLY HOSE ROUTING DIAGRAM 3 NOTE: Wing transport wheels are optional equipment, not available 15 FT. BASE WITH FLAT-FOLD WINGS on 3-6 ft. size wings. (3, 4, 5, 6, & 7 FT. WINGS) For Main Frame Plumbing--refer to PARTS section (page 59) for hoses, fitting types, and position.
  • Page 32 ASSEMBLY HOSE ROUTING DIAGRAM 4 NOTE: Wing transport wheels are optional equipment. 12 FT. BASE WITH STACK-FOLD WINGS (7 & 8 FT. WINGS) For Main Frame Plumbing--refer to PARTS section (page 60) for hoses, fitting types, and position. For Wing Transport Wheel Plumbing--refer To Tractor to PARTS section (page 64) for hoses, fit- ting types, and position.
  • Page 33 ASSEMBLY HOSE ROUTING DIAGRAM 5 NOTE: Wing transport wheels are optional equipment. 15 FT. BASE WITH STACK-FOLD WINGS (8, 9, 10, & 11 FT. WINGS) For Main Frame Plumbing--refer to PARTS section (page 62) for hoses, fitting types, and position. To Tractor For Wing Transport Wheel Plumbing--refer to PARTS section (page 64) for hoses, fit-...
  • Page 34 ASSEMBLY VIEW "J" Position this port (on both cylinders) on bottom-side (of cylinders). To "Rod-End Port" of R.H. Wing Fold Cylinder Stack-Fold Valve (See page 28) Elbow 12 FT. BASE MODEL SHOWN See View "K" OM-00842 35. PURGE THE AIR FROM THE HYDRAU- VIEW "K"...
  • Page 35 ASSEMBLY Also check to make sure that the actuator UNIT LESS WINGS bracket strikes the "Plunger" of the stack fold 36. PURGE THE AIR FROM THE TRANS- valve squarely and on center (in the folded PORT CYLINDERS. position). Recheck location dimension for proper alignment.
  • Page 36 ASSEMBLY ONE-BAR ASSEMBLY Assembly of the one-bar/rolling harrow to the NOTE: Refer to Diagonal/Round-Tooth One- machine is best accomplished with the wings Bar layouts for mounting arm and "Y" tooth unfolded and the unit raised for transport. location (page 42). 42.
  • Page 37 ASSEMBLY TRANSPORT WHEELS USED WITH COIL-TINE DRAG BAR COIL-TINE DRAG BARS 45. Refer to the table (below) for determining one-bar length required, on each section. Remove one of the 5/16-18 x 1 3/4" capscrews (9390-062) and locknut (9928) "A" DIM. ONE-BAR TUBE that is directly behind the wing tansport...
  • Page 38 ASSEMBLY ROLLING HARROW ASSEMBLY 47. Refer to table (below) for determining roll- 48. Position rolling harrow assembly to mount- ing harrow width required, on each section. ing arms, align holes and install 1" dia. x 5 1/4" lg. pins (82381). Retain into position with two spiral pins (91144-186) "A"...
  • Page 39 ASSEMBLY JACKSTAND 51. Position jackmount (82303) to rear of main frame at the center of unit (Fig. 3-20). Retain into position with four 5/8-11 x 3" lg. capscrews (9390-128) and locknuts (9801). 52. Insert jackstand (82307) into mount and retain with 3/4" dia. x 5 1/4" pin (82412) and klik-pin (91058) in desired position: Align vertical holes and install pin for "PARKED"...
  • Page 40 ASSEMBLY REFLECTORS 55. INSTALL REFLECTOR TO THE ROLLING HARROW FRAME (FIG. 3-22). UNITS WITH WINGS Install red reflector onto rear hinge plate of wing frame (Fig. 3-23). UNITS LESS WINGS Install onto outside ends of the main frame, below the hinge point. FIG.
  • Page 49 9661 Hose Holder 9800 Locknut 1/2-13 95445 Decal - WARNING (Hydraulic) 94094 Decal - WARNING (Tipping) 9951 Klik Pin 93719 Decal - "ROLLING HARROW II" 91363 Pin 1" Dia. x 6" Lg. 93718 Decal - "UNVERFERTH" 93720 Decal - Stripe...
  • Page 51 PARTS MAIN FRAME/AXLE ASSEMBLY ITEM PART NO. DESCRIPTION QTY. 81460 Main Frame Weldment 12' 81461 Main Frame Weldment 15' 81498 1 1/2" Dia. x 9 1/4" Lg. Pin 81569 Stand Weldment 3-5' Wings 81837 Axle Weldment 82412 3/4" Dia. x 5 1/4" Lg. Pin 82303 Jack Mount Weldment 82307...
  • Page 52 PARTS WINGS - 12' BASE & 15' BASE (3', 4', 5', & 6' SIZES) OM-00858 PART NO. DESCRIPTION 12' BASE ITEM 15' BASE 83244 Pin 1 1/4" Dia. x 2 5/8" Lg. 84736 Linkage Bar (15' Base Only) 83262 Pin 1 1/4" Dia. x 2 3/8" Lg. 83263 Pin 1 1/4' Dia.
  • Page 53 PARTS WINGS - 12' BASE & 15' BASE (7', 8', 9', 10', & 11' SIZES) OM-00859 ITEM PART NO. DESCRIPTION 83244 Pin 1 1/4 Dia. x 2 5/8" Lg. 81503 Arm (12' Base Only) 81506 Linkage Bar (12' Base Only) 83262 Pin 1 1/4"...
  • Page 64 PARTS WING TRANSPORT WHEEL/HYDRAULICS OM-00870 QTY. PER MACHINE ITEM PART NO. DESCRIPTION BASE WINGS 85632 Pin 1" Dia. x 3 3/4" Lg. 83235 Pin 1" Dia. x 3 3/8" Lg. 81486 RH Axle Weldment (Shown) 81487 LH Axle Weldment 81498 Pin 1 1/2"...
  • Page 65 PARTS VALVE/ACTUATOR ASSEMBLY (STACK-FOLD WINGS) ITEM PART NO. DESCRIPTION 84160 Retainer 81688 Pin 5/16" Dia. x 1 1/8" Lg. 9390-018 Capscrew 1/4-20 x 4 1/2" Lg. 9936 Locknut 1/4-20 91470 Valve 91472 Spring 91541 Washer 95645 Boot 91543 Hose Clamp 92952 Seal Kit For Valve (91470) 95634...
  • Page 66 MAR/SG/S:\MANUALS\84914.P65-111997-2/020998-3/November 2013-4...
