3.9.3 Monitoring parameter list (press P + press foot lifter key to enter)
Number
M10 Stitches account number
M11 Pieces account number
M13 Panel version number
Main board version number for
M18
control box
M20 Generatrix Voltage
M21 Machine speed
Stepmotor Electric Angle
M58
4 Error code

4.1 Error code list

If have Error or alarm, please check first as follows:1. Check the connection wire is connected or not; 2.
Check the machine head is matched with the control box; 3. check reset is accurate or not.

Error number

Code meaning
Arm shaft motor
Err-01
hardware overcurrent
Err-03 System undervoltage
Overvoltage during
Err-04
Overvoltage during
Err-05
Electromagnet circuit
Err-06
Arm shaft motor
Err-07 current detection
circuit failure
Description
1. Turn off the system power, and turn it on again after 30 seconds.
2. Check whether the arm shaft motor encoder and electronic control are damaged
or in other poor conditions. If so, replace them in time.
3. If the system still does not work properly after troubleshooting and restart.
Please contact your local service provider or call 4008876858.
Disconnect the power supply of the controller and check whether the input power
supply voltage is lower than 176V. If so, please restart the controller after the
voltage returns to normal. If the voltage returns to normal, it still does not work
properly after the controller starts up. Please contact your local service provider or
call 4008876858.
Disconnect the controller power and check whether the input power voltage is
higher than 264V. If so, please restart the controller after the voltage returns to
shutdown normal. If the voltage returns to normal, it still does not work properly after the
controller starts up.Please contact your local service provider or call 4008876858.
Disconnect the controller power and check whether the input power voltage is
higher than 264V. If so, please restart the controller after the voltage returns to
operation normal. If the voltage returns to normal, it still does not work properly after the
controller starts up.Please contact your local service provider or call 4008876858.
1. Turn off the system power, check whether the electromagnet connection is
correct and whether there is any loose or damaged part. If so, replace it in time.
2. Unplug the electromagnet plug on the electric control to confirm whether the
electric control is normal. If the electric control is normal, please check whether
failure
the electromagnetic circuits are damaged.
3. If the system still does not work after troubleshooting and restart.
Please contact your local service provider or call 4008876858.
Turn off the system power, and turn on the power again after 30 seconds to see
whether it can work properly. Try a few times again. If the fault occurs frequently,
please contact your local service provider or call 4008876858.
Number
M23 Initial angle
M24 Mechanical angle
M25 Max value for pedal forward press
M26 Sample value for pedal back
M28 Sample pedal value of trimming
M30-M37 Historical Error number
Stepmotor current value
M59
Solutions
12 / 14
